GE Multilin 489

A–14 489 GENERATOR MANAGEMENT RELAY – INSTRUCTION MANUAL
CHAPTER A: APPENDIX
Current transformers in most common ratios from 50:5 to 1000:5 are available for use as
phase current inputs with motor protection relays. These come with mounting hardware
and are also available with 1 A secondaries. Voltage class: 600 V BIL, 10 KV.
808712A1.CDR
Courtesy of NationalSwitchgear.com
