CHAPTER 4: INTERFACES
Z Select the File > Read Settings from Device menu item to obtain
settings information from the device.
After a few seconds of data retrieval, the software will request the name and destination
path of the setpoint file. The corresponding file extension will be automatically assigned.
Z Press Save to complete the process.
A new entry will be added to the tree, in the File pane, showing path and
file name for the setpoint file.
Adding Setpoints Files to the Environment
The EnerVista 489 Setup software provides the capability to review and manage a large
group of setpoint files. Use the following procedure to add a new or existing file to the list.
Z In the files pane, right-click on ‘Files’
Z Select the Add Existing Setting File item as shown:
The Open dialog box will appear, prompting for a previously saved setting file. As for any
other Windows
®
application,
Z Browse for the file to add.
Z Click Open.
The new file and complete path will be added to the file list.
Creating a New Setpoint File
The EnerVista 489 Setup software allows the user to create new setpoint files independent
of a connected device. These can be uploaded to a relay at a later date. The following
procedure illustrates how to create new setpoint files.
Z In the File pane, right click on ‘File’.
