GE Multilin 745 - Page 95

Setpoints
http://www.GEindustrial.com/multilin
5–21
GE Multilin
Auto-Configuration
745
Transformer Management Relay
D/y150°/
d180°
1DELTA 0°
2WYE
(gnd 1/2)
150° lag
210°
lag
3DELTA
180° lag
180°
lag
D/y150°/
d300°
1DELTA 0°
2WYE
(gnd 1/2)
150° lag
210°
lag
3DELTA
300° lag
60°
lag
D/y150°/
y150°
1DELTA 0°
2WYE
(gnd 1/2)
150° lag
210°
lag
3WYE
(gnd 2/3)
150° lag
210°
lag
D/y150°/
y330°
1DELTA 0°
2WYE
(gnd 1/2)
150° lag
210°
lag
3WYE
(gnd 2/3)
330° lag
30°
lag
Table 5–1: Transformer Types (Sheet 21 of 24)
Transformer
Type
Wdg # Connection Voltage
Phasors
Phase
Shift
D/y210°/
d0°
1DELTA 0°
2WYE
(gnd 1/2)
210° lag
150°
lag
3DELTA
0°
0°
D/y210°/
d60°
1DELTA 0°
2WYE
(gnd 1/2)
210° lag
150°
lag
3DELTA
60° lag
300°
lag
D/y210°/
d240°
1DELTA 0°
2WYE
(gnd 1/2)
210° lag
150°
lag
3DELTA
240° lag
120°
lag
D/y210°/
y30°
1DELTA 0°
2WYE
(gnd 1/2)
210° lag
150°
lag
3WYE
(gnd 2/3)
30° lag
330°
lag
D/y210°/
y210°
1DELTA 0°
2WYE
(gnd 1/2)
210° lag
150°
lag
3WYE
(gnd 2/3)
210° lag
150°
lag
Table 5–1: Transformer Types (Sheet 22 of 24)
Transformer
Type
Wdg # Connection Voltage
Phasors
Phase
Shift
