GE Multilin 745

A2 Metering
745
Transformer Management Relay
Actual Values
http://www.GEindustrial.com/multilin
6–5
GE Multilin
A2 Metering
Current a) Main Menu
PATH: ACTUAL VALUES !" A2 METERING ! CURRENT
For each monitored winding, the fundamental frequency magnitude and phase angle
of phase A, B, C and ground currents are recalculated every half-cycle for use in
differential and overcurrent protection. From these values, neutral, positive,
negative and zero-sequence as well as differential, restraint and ground differential
currents are calculated. These are displayed and updated approximately twice a
second for readability.
b) Winding Currents
PATH: ACTUAL VALUES !" A2 METERING ! CURRENT ! W1(3) CURRENT
! CURRENT [!] ! W1 CURRENT [!]
See below.
MESSAGE
! W2 CURRENT [!]
See below.
MESSAGE
! W3 CURRENT [!]
See below.
MESSAGE
! POSITIVE [!]
SEQUENCE
See page 6–6.
MESSAGE
! NEGATIVE [!]
SEQUENCE
See page 6–6.
MESSAGE
! ZERO SEQUENCE [!]
See page 6–6.
MESSAGE
! DIFFERENTIAL [!]
See page 6–7.
MESSAGE
! RESTRAINT [!]
See page 6–7.
MESSAGE
! GROUND [!]
DIFFERENTIAL
See page 6–7.
! W1 CURRENT [!] W1 PHASE A CURRENT:
0 A at 0° Lag
MESSAGE
W1 PHASE B CURRENT:
0 A at 0° Lag
MESSAGE
W1 PHASE C CURRENT:
0 A at 0° Lag
MESSAGE
W1 NEUTRAL CURRENT:
0 A at 0° Lag
MESSAGE
W1 GROUND CURRENT:
0 A at 0° Lag
MESSAGE
WINDING 1 LOADING:
0% of rated load
MESSAGE
W1 AVERAGE PHASE
CURRENT: 0 A
