GE Multilin g60

B-10 G60 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
User Displays Actuals (Read Only)
1080 Formatted user-definable displays (16 items) --- --- --- F200 (none)
Modbus User Map Actuals (Read Only)
1200 User Map Values (256 items) 0 to 65535 --- 1 F001 0
Element Targets (Read Only)
14C0 Target Sequence 0 to 65535 --- 1 F001 0
14C1 Number of Targets 0 to 65535 --- 1 F001 0
Element Targets (Read/Write)
14C2 Target to Read 0 to 65535 --- 1 F001 0
Element Targets (Read Only)
14C3 Target Message --- --- --- F200 “.”
Digital Input/Output States (Read Only)
1500 Contact Input States (6 items) 0 to 65535 --- 1 F500 0
1508 Virtual Input States (8 items) 0 to 65535 --- 1 F500 0
1510 Contact Output States (4 items) 0 to 65535 --- 1 F500 0
1518 Contact Output Current States (4 items) 0 to 65535 --- 1 F500 0
1520 Contact Output Voltage States (4 items) 0 to 65535 --- 1 F500 0
1528 Virtual Output States (6 items) 0 to 65535 --- 1 F500 0
1530 Contact Output Detectors (4 items) 0 to 65535 --- 1 F500 0
Remote Input/Output States (Read Only)
1540 Remote Device States 0 to 65535 --- 1 F500 0
1542 Remote Input States (4 items) 0 to 65535 --- 1 F500 0
1550 Remote Devices Online 0 to 1 --- 1 F126 0 (No)
1551 Remote Double-Point Status Input 1 State 0 to 3 --- 1 F605 3 (Bad)
1552 Remote Double-Point Status Input 2 State 0 to 3 --- 1 F605 3 (Bad)
1553 Remote Double-Point Status Input 3 State 0 to 3 --- 1 F605 3 (Bad)
1554 Remote Double-Point Status Input 4 State 0 to 3 --- 1 F605 3 (Bad)
1555 Remote Double-Point Status Input 5 State 0 to 3 --- 1 F605 3 (Bad)
Platform Direct Input/Output States (Read Only)
15C0 Direct input states (6 items) 0 to 65535 --- 1 F500 0
15C8 Direct outputs average message return time 1 0 to 65535 ms 1 F001 0
15C9 Direct outputs average message return time 2 0 to 65535 ms 1 F001 0
15CA Direct inputs/outputs unreturned message count - Ch. 1 0 to 65535 --- 1 F001 0
15CB Direct inputs/outputs unreturned message count - Ch. 2 0 to 65535 --- 1 F001 0
15D0 Direct device states 0 to 65535 --- 1 F500 0
15D1 Reserved 0 to 65535 --- 1 F001 0
15D2 Direct inputs/outputs CRC fail count 1 0 to 65535 --- 1 F001 0
15D3 Direct inputs/outputs CRC fail count 2 0 to 65535 --- 1 F001 0
Ethernet Fibre Channel Status (Read/Write)
1610 Ethernet primary fibre channel status 0 to 2 --- 1 F134 0 (Fail)
1611 Ethernet secondary fibre channel status 0 to 2 --- 1 F134 0 (Fail)
Data Logger Actuals (Read Only)
1618 Data logger channel count 0 to 16 channel 1 F001 0
1619 Time of oldest available samples 0 to 4294967295 seconds 1 F050 0
161B Time of newest available samples 0 to 4294967295 seconds 1 F050 0
161D Data logger duration 0 to 999.9 days 0.1 F001 0
Stator Differential Actuals (Read Only)
1660 Generator Differential Iad 0 to 999999.999 A 0.001 F060 0
1662 Generator Restraint Iar 0 to 999999.999 A 0.001 F060 0
1664 Generator Differential Ibd 0 to 999999.999 A 0.001 F060 0
1666 Generator Restraint Ibr 0 to 999999.999 A 0.001 F060 0
1668 Generator Differential Icd 0 to 999999.999 A 0.001 F060 0
166A Generator Restraint Icr 0 to 999999.999 A 0.001 F060 0
166C Stator Differential CT Primary 0 to 50000 --- 1 F060 1
Table B–9: MODBUS MEMORY MAP (Sheet 3 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
