GE Multilin g60

GE Multilin G60 Generator Protection System B-11
APPENDIX B B.4 MEMORY MAPPING
B
Stator Ground Actuals (Read Only)
1670 Stator Ground Vn 3rd 0 to 999999.999 V 0.001 F060 0
1672 Stator Ground Vn V0 3rd 0 to 999999.999 V 0.001 F060 0
1674 Stator Ground V0 3rd 0 to 999999.999 V 0.001 F060 0
Sensitive Directional Power Actuals (Read Only) (2 modules)
1680 Sensitive Directional Power 1 Power
-2147483647 to 2147483647
W 1 F060 0
1682 Sensitive Directional Power 2 Power
-2147483647 to 2147483647
W 1 F060 0
Restricted Ground Fault Currents (Read Only) (6 modules)
16A0 Differential Ground Current Magnitude 0 to 999999.999 A 0.001 F060 0
16A2 Restricted Ground Current Magnitude 0 to 999999.999 A 0.001 F060 0
16A4 ...Repeated for Restricted Ground Fault 2
16A8 ...Repeated for Restricted Ground Fault 3
16AC ...Repeated for Restricted Ground Fault 4
16B0 ...Repeated for Restricted Ground Fault 5
16B4 ...Repeated for Restricted Ground Fault 6
Frequency Rate of Change Actuals (Read Only) (4 modules)
16E0 Frequency Rate of Change 1 -327.67 to 327.67 Hz/s 0.01 F002 0
16E1 Reserved (3 items) 0 to 65535 --- 1 F001 0
16E4 ...Repeated for Frequency Rate of Change 2
16E8 ...Repeated for Frequency Rate of Change 3
16EC ...Repeated for Frequency Rate of Change 4
Source Current (Read Only) (6 modules)
1800 Source 1 Phase A Current RMS 0 to 999999.999 A 0.001 F060 0
1802 Source 1 Phase B Current RMS 0 to 999999.999 A 0.001 F060 0
1804 Source 1 Phase C Current RMS 0 to 999999.999 A 0.001 F060 0
1806 Source 1 Neutral Current RMS 0 to 999999.999 A 0.001 F060 0
1808 Source 1 Phase A Current Magnitude 0 to 999999.999 A 0.001 F060 0
180A Source 1 Phase A Current Angle -359.9 to 0 degrees 0.1 F002 0
180B Source 1 Phase B Current Magnitude 0 to 999999.999 A 0.001 F060 0
180D Source 1 Phase B Current Angle -359.9 to 0 degrees 0.1 F002 0
180E Source 1 Phase C Current Magnitude 0 to 999999.999 A 0.001 F060 0
1810 Source 1 Phase C Current Angle -359.9 to 0 degrees 0.1 F002 0
1811 Source 1 Neutral Current Magnitude 0 to 999999.999 A 0.001 F060 0
1813 Source 1 Neutral Current Angle -359.9 to 0 degrees 0.1 F002 0
1814 Source 1 Ground Current RMS 0 to 999999.999 A 0.001 F060 0
1816 Source 1 Ground Current Magnitude 0 to 999999.999 A 0.001 F060 0
1818 Source 1 Ground Current Angle -359.9 to 0 degrees 0.1 F002 0
1819 Source 1 Zero Sequence Current Magnitude 0 to 999999.999 A 0.001 F060 0
181B Source 1 Zero Sequence Current Angle -359.9 to 0 degrees 0.1 F002 0
181C Source 1 Positive Sequence Current Magnitude 0 to 999999.999 A 0.001 F060 0
181E Source 1 Positive Sequence Current Angle -359.9 to 0 degrees 0.1 F002 0
181F Source 1 Negative Sequence Current Magnitude 0 to 999999.999 A 0.001 F060 0
1821 Source 1 Negative Sequence Current Angle -359.9 to 0 degrees 0.1 F002 0
1822 Source 1 Differential Ground Current Magnitude 0 to 999999.999 A 0.001 F060 0
1824 Source 1 Differential Ground Current Angle -359.9 to 0 degrees 0.1 F002 0
1825 Reserved (27 items) --- --- --- F001 0
1840 ...Repeated for Source 2
1880 ...Repeated for Source 3
18C0 ...Repeated for Source 4
1900 ...Repeated for Source 5
1940 ...Repeated for Source 6
Source Voltage (Read Only) (6 modules)
1A00 Source 1 Phase AG Voltage RMS V F060 0
1A02 Source 1 Phase BG Voltage RMS V F060 0
Table B–9: MODBUS MEMORY MAP (Sheet 4 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
