B.4 MEMORY MAPPING APPENDIX B
B
1A04 Source 1 Phase CG Voltage RMS V F060 0
1A06 Source 1 Phase AG Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
1A08 Source 1 Phase AG Voltage Angle -359.9 to 0 degrees 0.1 F002 0
1A09 Source 1 Phase BG Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
1A0B Source 1 Phase BG Voltage Angle -359.9 to 0 degrees 0.1 F002 0
1A0C Source 1 Phase CG Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
1A0E Source 1 Phase CG Voltage Angle -359.9 to 0 degrees 0.1 F002 0
1A0F Source 1 Phase AB or AC Voltage RMS 0 to 999999.999 V 0.001 F060 0
1A11 Source 1 Phase BC or BA Voltage RMS 0 to 999999.999 V 0.001 F060 0
1A13 Source 1 Phase CA or CB Voltage RMS 0 to 999999.999 V 0.001 F060 0
1A15 Source 1 Phase AB or AC Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
1A17 Source 1 Phase AB or AC Voltage Angle -359.9 to 0 degrees 0.1 F002 0
1A18 Source 1 Phase BC or BA Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
1A1A Source 1 Phase BC or BA Voltage Angle -359.9 to 0 degrees 0.1 F002 0
1A1B Source 1 Phase CA or CB Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
1A1D Source 1 Phase CA or CB Voltage Angle -359.9 to 0 degrees 0.1 F002 0
1A1E Source 1 Auxiliary Voltage RMS V F060 0
1A20 Source 1 Auxiliary Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
1A22 Source 1 Auxiliary Voltage Angle -359.9 to 0 degrees 0.1 F002 0
1A23 Source 1 Zero Sequence Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
1A25 Source 1 Zero Sequence Voltage Angle -359.9 to 0 degrees 0.1 F002 0
1A26 Source 1 Positive Sequence Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
1A28 Source 1 Positive Sequence Voltage Angle -359.9 to 0 degrees 0.1 F002 0
1A29 Source 1 Negative Sequence Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
1A2B Source 1 Negative Sequence Voltage Angle -359.9 to 0 degrees 0.1 F002 0
1A2C Reserved (20 items) --- --- --- F001 0
1A40 ...Repeated for Source 2
1A80 ...Repeated for Source 3
1AC0 ...Repeated for Source 4
1B00 ...Repeated for Source 5
1B40 ...Repeated for Source 6
Source Power (Read Only) (6 modules)
1C00 Source 1 Three Phase Real Power -1000000000000 to
1000000000000
W 0.001 F060 0
1C02 Source 1 Phase A Real Power -1000000000000 to
1000000000000
W 0.001 F060 0
1C04 Source 1 Phase B Real Power -1000000000000 to
1000000000000
W 0.001 F060 0
1C06 Source 1 Phase C Real Power -1000000000000 to
1000000000000
W 0.001 F060 0
1C08 Source 1 Three Phase Reactive Power -1000000000000 to
1000000000000
var 0.001 F060 0
1C0A Source 1 Phase A Reactive Power -1000000000000 to
1000000000000
var 0.001 F060 0
1C0C Source 1 Phase B Reactive Power -1000000000000 to
1000000000000
var 0.001 F060 0
1C0E Source 1 Phase C Reactive Power -1000000000000 to
1000000000000
var 0.001 F060 0
1C10 Source 1 Three Phase Apparent Power -1000000000000 to
1000000000000
VA 0.001 F060 0
1C12 Source 1 Phase A Apparent Power -1000000000000 to
1000000000000
VA 0.001 F060 0
1C14 Source 1 Phase B Apparent Power -1000000000000 to
1000000000000
VA 0.001 F060 0
1C16 Source 1 Phase C Apparent Power -1000000000000 to
1000000000000
VA 0.001 F060 0
1C18 Source 1 Three Phase Power Factor -0.999 to 1 --- 0.001 F013 0
1C19 Source 1 Phase A Power Factor -0.999 to 1 --- 0.001 F013 0
Table B–9: MODBUS MEMORY MAP (Sheet 5 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
