B-14 G60 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
254C PMU 1 Positive Sequence Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
254E PMU 1 Positive Sequence Voltage Angle -359.9 to 0 ° 0.1 F002 0
254F PMU 1 Negative Sequence Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
2551 PMU 1 Negative Sequence Voltage Angle -359.9 to 0 ° 0.1 F002 0
2552 PMU 1 Zero Sequence Voltage Magnitude 0 to 999999.999 V 0.001 F060 0
2554 PMU 1 Zero Sequence Voltage Angle -359.9 to 0 ° 0.1 F002 0
2555 PMU 1 Phase A Current Magnitude 0 to 999999.999 A 0.001 F060 0
2557 PMU 1 Phase A Current Angle -359.9 to 0 ° 0.1 F002 0
2558 PMU 1 Phase B Current Magnitude 0 to 999999.999 A 0.001 F060 0
255A PMU 1 Phase B Current Angle -359.9 to 0 ° 0.1 F002 0
255B PMU 1 Phase C Current Magnitude 0 to 999999.999 A 0.001 F060 0
255D PMU 1 Phase C Current Angle -359.9 to 0 ° 0.1 F002 0
255E PMU 1 Ground Current Magnitude 0 to 999999.999 A 0.001 F060 0
2560 PMU 1 Ground Current Angle -359.9 to 0 ° 0.1 F002 0
2561 PMU 1 Positive Sequence Current Magnitude 0 to 999999.999 A 0.001 F060 0
2563 PMU 1 Positive Sequence Current Angle -359.9 to 0 ° 0.1 F002 0
2564 PMU 1 Negative Sequence Current Magnitude 0 to 999999.999 A 0.001 F060 0
2566 PMU 1 Negative Sequence Current Angle -359.9 to 0 ° 0.1 F002 0
2567 PMU 1 Zero Sequence Current Magnitude 0 to 999999.999 A 0.001 F060 0
2569 PMU 1 Zero Sequence Current Angle -359.9 to 0 ° 0.1 F002 0
256A PMU 1 Frequency 2 to 90 Hz 0.001 F003 0
256C PMU 1 df/dt -327.67 to 327.67 Hz/s 0.01 F002 0
256D PMU 1 Configuration Change Counter 0 to 655.35 0.01 F001 0
256E Reserved (4 items) 0 to 1 --- 1 F001 0
Phasor measurement unit integer values (read only actual value registers)
2608 PMU 1 SOC timestamp 0 to 4294967295 seconds 1 F003 0
260A PMU 1 FRAMESEC timestamp 0 to 4294967295 seconds 1 F003 0
260C PMU 1 STAT flags 0 to 4294967295 --- 1 F003 0
Remote double-point status inputs (read/write setting registers)
2620 Remote double-point status input 1 device 1 to 32 --- 1 F001 1
2621 Remote double-point status input 1 item 0 to 128 --- 1 F156 0 (None)
2622 Remote double-point status input 1 name 1 to 64 --- 1 F205 "Rem Ip 1"
2628 Remote double-point status input 1 events 0 to 1 --- 1 F102 0 (Disabled)
2629 ... Repeated for double-point status input 2
2632 ... Repeated for double-point status input 3
263B ... Repeated for double-point status input 4
2644 ... Repeated for double-point status input 5
IEC 61850 GGIO5 configuration (read/write setting registers)
26B0 IEC 61850 GGIO5 uinteger input 1 operand --- --- --- F612 0
26B1 IEC 61850 GGIO5 uinteger input 2 operand --- --- --- F612 0
26B2 IEC 61850 GGIO5 uinteger input 3 operand --- --- --- F612 0
26B3 IEC 61850 GGIO5 uinteger input 4 operand --- --- --- F612 0
26B4 IEC 61850 GGIO5 uinteger input 5 operand --- --- --- F612 0
26B5 IEC 61850 GGIO5 uinteger input 6 operand --- --- --- F612 0
26B6 IEC 61850 GGIO5 uinteger input 7 operand --- --- --- F612 0
26B7 IEC 61850 GGIO5 uinteger input 8 operand --- --- --- F612 0
26B8 IEC 61850 GGIO5 uinteger input 9 operand --- --- --- F612 0
26B9 IEC 61850 GGIO5 uinteger input 10 operand --- --- --- F612 0
26BA IEC 61850 GGIO5 uinteger input 11 operand --- --- --- F612 0
26BB IEC 61850 GGIO5 uinteger input 12 operand --- --- --- F612 0
26BC IEC 61850 GGIO5 uinteger input 13 operand --- --- --- F612 0
26BD IEC 61850 GGIO5 uinteger input 14 operand --- --- --- F612 0
26BE IEC 61850 GGIO5 uinteger input 15 operand --- --- --- F612 0
26BF IEC 61850 GGIO5 uinteger input 16 operand --- --- --- F612 0
Table B–9: MODBUS MEMORY MAP (Sheet 7 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
