GE Multilin g60

GE Multilin G60 Generator Protection System B-15
APPENDIX B B.4 MEMORY MAPPING
B
IEC 61850 received integers (read only actual values)
26F0 IEC 61850 received uinteger 1 0 to 4294967295 --- 1 F003 0
26F2 IEC 61850 received uinteger 2 0 to 4294967295 --- 1 F003 0
26F4 IEC 61850 received uinteger 3 0 to 4294967295 --- 1 F003 0
26F6 IEC 61850 received uinteger 4 0 to 4294967295 --- 1 F003 0
26F8 IEC 61850 received uinteger 5 0 to 4294967295 --- 1 F003 0
26FA IEC 61850 received uinteger 6 0 to 4294967295 --- 1 F003 0
26FC IEC 61850 received uinteger 7 0 to 4294967295 --- 1 F003 0
26FE IEC 61850 received uinteger 8 0 to 4294967295 --- 1 F003 0
2700 IEC 61850 received uinteger 9 0 to 4294967295 --- 1 F003 0
2702 IEC 61850 received uinteger 10 0 to 4294967295 --- 1 F003 0
2704 IEC 61850 received uinteger 11 0 to 4294967295 --- 1 F003 0
2706 IEC 61850 received uinteger 12 0 to 4294967295 --- 1 F003 0
2708 IEC 61850 received uinteger 13 0 to 4294967295 --- 1 F003 0
270A IEC 61850 received uinteger 14 0 to 4294967295 --- 1 F003 0
270C IEC 61850 received uinteger 15 0 to 4294967295 --- 1 F003 0
270E IEC 61850 received uinteger 16 0 to 4294967295 --- 1 F003 0
Source Current THD And Harmonics (Read Only) (6 modules)
2800 Ia THD for Source 1 0 to 99.9 --- 0.1 F001 0
2801 Ia Harmonics for Source 1 - 2nd to 25th (24 items) 0 to 99.9 --- 0.1 F001 0
2821 Ib THD for Source 1 0 to 99.9 --- 0.1 F001 0
2822 Ib Harmonics for Source 1 - 2nd to 25th (24 items) 0 to 99.9 --- 0.1 F001 0
283A Reserved (8 items) 0 to 0.1 --- 0.1 F001 0
2842 Ic THD for Source 1 0 to 99.9 --- 0.1 F001 0
2843 Ic Harmonics for Source 1 - 2nd to 25th (24 items) 0 to 99.9 --- 0.1 F001 0
285B Reserved (8 items) 0 to 0.1 --- 0.1 F001 0
2863 ...Repeated for Source 2
28C6 ...Repeated for Source 3
2929 ...Repeated for Source 4
Expanded FlexStates (Read Only)
2B00 FlexStates, one per register (256 items) 0 to 1 --- 1 F108 0 (Off)
Expanded Digital Input/Output states (Read Only)
2D00 Contact Input States, one per register (96 items) 0 to 1 --- 1 F108 0 (Off)
2D80 Contact Output States, one per register (64 items) 0 to 1 --- 1 F108 0 (Off)
2E00 Virtual Output States, one per register (96 items) 0 to 1 --- 1 F108 0 (Off)
Expanded Remote Input/Output Status (Read Only)
2F00 Remote Device States, one per register (16 items) 0 to 1 --- 1 F155 0 (Offline)
2F80 Remote Input States, one per register (64 items) 0 to 1 --- 1 F108 0 (Off)
Oscillography Values (Read Only)
3000 Oscillography Number of Triggers 0 to 65535 --- 1 F001 0
3001 Oscillography Available Records 0 to 65535 --- 1 F001 0
3002 Oscillography Last Cleared Date 0 to 400000000 --- 1 F050 0
3004 Oscillography Number Of Cycles Per Record 0 to 65535 --- 1 F001 0
Oscillography Commands (Read/Write Command)
3005 Oscillography Force Trigger 0 to 1 --- 1 F126 0 (No)
3011 Oscillography Clear Data 0 to 1 --- 1 F126 0 (No)
3012 Oscillography Number of Triggers 0 to 32767 --- 1 F001 0
User Programmable Fault Report Commands (Read/Write Command)
3060 User Fault Report Clear 0 to 1 --- 1 F126 0 (No)
User Programmable Fault Report Actuals (Read Only)
3070 Newest Record Number 0 to 65535 --- 1 F001 0
3071 Cleared Date 0 to 4294967295 --- 1 F050 0
3073 Report Date (10 items) 0 to 4294967295 --- 1 F050 0
Table B–9: MODBUS MEMORY MAP (Sheet 8 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
