B-16 G60 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
User Programmable Fault Report (Read/Write Setting) (2 modules)
3090 Fault Report 1 Fault Trigger 0 to 65535 --- 1 F300 0
3091 Fault Report 1 Function 0 to 1 --- 1 F102 0 (Disabled)
3092 Fault Report 1 Prefault Trigger 0 to 65535 --- 1 F300 0
3093 Fault Report Analog Channel 1 (32 items) 0 to 65536 --- 1 F600 0
30B3 Fault Report 1 Reserved (5 items) --- --- --- F001 0
30B8 ...Repeated for Fault Report 2
Modbus file transfer (read/write)
3100 Name of file to read --- --- --- F204 (none)
Modbus file transfer values (read only)
3200 Character position of current block within file 0 to 4294967295 --- 1 F003 0
3202 Size of currently-available data block 0 to 65535 --- 1 F001 0
3203 Block of data from requested file (122 items) 0 to 65535 --- 1 F001 0
Event recorder actual values (read only)
3400 Events Since Last Clear 0 to 4294967295 --- 1 F003 0
3402 Number of Available Events 0 to 4294967295 --- 1 F003 0
3404 Event Recorder Last Cleared Date 0 to 4294967295 --- 1 F050 0
Event recorder commands (read/write)
3406 Event Recorder Clear Command 0 to 1 --- 1 F126 0 (No)
DCMA Input Values (Read Only) (24 modules)
34C0 DCMA Inputs 1 Value -9999999 to 9999999 --- 1 F004 0
34C2 DCMA Inputs 2 Value -9999999 to 9999999 --- 1 F004 0
34C4 DCMA Inputs 3 Value -9999999 to 9999999 --- 1 F004 0
34C6 DCMA Inputs 4 Value -9999999 to 9999999 --- 1 F004 0
34C8 DCMA Inputs 5 Value -9999999 to 9999999 --- 1 F004 0
34CA DCMA Inputs 6 Value -9999999 to 9999999 --- 1 F004 0
34CC DCMA Inputs 7 Value -9999999 to 9999999 --- 1 F004 0
34CE DCMA Inputs 8 Value -9999999 to 9999999 --- 1 F004 0
34D0 DCMA Inputs 9 Value -9999999 to 9999999 --- 1 F004 0
34D2 DCMA Inputs 10 Value -9999999 to 9999999 --- 1 F004 0
34D4 DCMA Inputs 11 Value -9999999 to 9999999 --- 1 F004 0
34D6 DCMA Inputs 12 Value -9999999 to 9999999 --- 1 F004 0
34D8 DCMA Inputs 13 Value -9999999 to 9999999 --- 1 F004 0
34DA DCMA Inputs 14 Value -9999999 to 9999999 --- 1 F004 0
34DC DCMA Inputs 15 Value -9999999 to 9999999 --- 1 F004 0
34DE DCMA Inputs 16 Value -9999999 to 9999999 --- 1 F004 0
34E0 DCMA Inputs 17 Value -9999999 to 9999999 --- 1 F004 0
34E2 DCMA Inputs 18 Value -9999999 to 9999999 --- 1 F004 0
34E4 DCMA Inputs 19 Value -9999999 to 9999999 --- 1 F004 0
34E6 DCMA Inputs 20 Value -9999999 to 9999999 --- 1 F004 0
34E8 DCMA Inputs 21 Value -9999999 to 9999999 --- 1 F004 0
34EA DCMA Inputs 22 Value -9999999 to 9999999 --- 1 F004 0
34EC DCMA Inputs 23 Value -9999999 to 9999999 --- 1 F004 0
34EE DCMA Inputs 24 Value -9999999 to 9999999 --- 1 F004 0
RTD Input Values (Read Only) (48 modules)
34F0 RTD Input 1 Value -32768 to 32767 °C 1 F002 0
34F1 RTD Input 2 Value -32768 to 32767 °C 1 F002 0
34F2 RTD Input 3 Value -32768 to 32767 °C 1 F002 0
34F3 RTD Input 4 Value -32768 to 32767 °C 1 F002 0
34F4 RTD Input 5 Value -32768 to 32767 °C 1 F002 0
34F5 RTD Input 6 Value -32768 to 32767 °C 1 F002 0
34F6 RTD Input 7 Value -32768 to 32767 °C 1 F002 0
34F7 RTD Input 8 Value -32768 to 32767 °C 1 F002 0
34F8 RTD Input 9 Value -32768 to 32767 °C 1 F002 0
Table B–9: MODBUS MEMORY MAP (Sheet 9 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
