GE Multilin G60 Generator Protection System B-17
APPENDIX B B.4 MEMORY MAPPING
B
34F9 RTD Input 10 Value -32768 to 32767 °C 1 F002 0
34FA RTD Input 11 Value -32768 to 32767 °C 1 F002 0
34FB RTD Input 12 Value -32768 to 32767 °C 1 F002 0
34FC RTD Input 13 Value -32768 to 32767 °C 1 F002 0
34FD RTD Input 14 Value -32768 to 32767 °C 1 F002 0
34FE RTD Input 15 Value -32768 to 32767 °C 1 F002 0
34FF RTD Input 16 Value -32768 to 32767 °C 1 F002 0
3500 RTD Input 17 Value -32768 to 32767 °C 1 F002 0
3501 RTD Input 18 Value -32768 to 32767 °C 1 F002 0
3502 RTD Input 19 Value -32768 to 32767 °C 1 F002 0
3503 RTD Input 20 Value -32768 to 32767 °C 1 F002 0
3504 RTD Input 21 Value -32768 to 32767 °C 1 F002 0
3505 RTD Input 22 Value -32768 to 32767 °C 1 F002 0
3506 RTD Input 23 Value -32768 to 32767 °C 1 F002 0
3507 RTD Input 24 Value -32768 to 32767 °C 1 F002 0
3508 RTD Input 25 Value -32768 to 32767 °C 1 F002 0
3509 RTD Input 26 Value -32768 to 32767 °C 1 F002 0
350A RTD Input 27 Value -32768 to 32767 °C 1 F002 0
350B RTD Input 28 Value -32768 to 32767 °C 1 F002 0
350C RTD Input 29 Value -32768 to 32767 °C 1 F002 0
350D RTD Input 30 Value -32768 to 32767 °C 1 F002 0
350E RTD Input 31 Value -32768 to 32767 °C 1 F002 0
350F RTD Input 32 Value -32768 to 32767 °C 1 F002 0
3510 RTD Input 33 Value -32768 to 32767 °C 1 F002 0
3511 RTD Input 34 Value -32768 to 32767 °C 1 F002 0
3512 RTD Input 35 Value -32768 to 32767 °C 1 F002 0
3513 RTD Input 36 Value -32768 to 32767 °C 1 F002 0
3514 RTD Input 37 Value -32768 to 32767 °C 1 F002 0
3515 RTD Input 38 Value -32768 to 32767 °C 1 F002 0
3516 RTD Input 39 Value -32768 to 32767 °C 1 F002 0
3517 RTD Input 40 Value -32768 to 32767 °C 1 F002 0
3518 RTD Input 41 Value -32768 to 32767 °C 1 F002 0
3519 RTD Input 42 Value -32768 to 32767 °C 1 F002 0
351A RTD Input 43 Value -32768 to 32767 °C 1 F002 0
351B RTD Input 44 Value -32768 to 32767 °C 1 F002 0
351C RTD Input 45 Value -32768 to 32767 °C 1 F002 0
351D RTD Input 46 Value -32768 to 32767 °C 1 F002 0
351E RTD Input 47 Value -32768 to 32767 °C 1 F002 0
351F RTD Input 48 Value -32768 to 32767 °C 1 F002 0
Expanded Direct Input/Output Status (Read Only)
3560 Direct Device States, one per register (8 items) 0 to 1 --- 1 F155 0 (Offline)
3570 Direct Input States, one per register (96 items) 0 to 1 --- 1 F108 0 (Off)
Frequency out-of-band accumulation actual values (read only)
37A0 Frequency OOB Accumulator Band 1 Accumulation 0.0 to 999.9 % 0.1 F001 0
37A1 Frequency OOB Accumulator Band 2 Accumulation 0.0 to 999.9 % 0.1 F001 0
37A2 Frequency OOB Accumulator Band 3 Accumulation 0.0 to 999.9 % 0.1 F001 0
37A3 Frequency OOB Accumulator Band 4 Accumulation 0.0 to 999.9 % 0.1 F001 0
37A4 Frequency OOB Accumulator Band 5 Accumulation 0.0 to 999.9 % 0.1 F001 0
37A5 Frequency OOB Accumulator Band 6 Accumulation 0.0 to 999.9 % 0.1 F001 0
37A6 Frequency OOB Accumulator Band 7 Accumulation 0.0 to 999.9 % 0.1 F001 0
Frequency out-of-band accumulation commands (read/write)
37A7 Reset Frequency Out-Of-Band Accumulators 0 to 1 --- 1 F126 0 (No)
37A8 Preset Frequency Out-Of-Band Accumulators 0 to 1 --- 1 F126 0 (No)
Table B–9: MODBUS MEMORY MAP (Sheet 10 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
