B-28 G60 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
5D04 Ground Time Overcurrent 1 Curve 0 to 16 --- 1 F103 0 (IEEE Mod Inv)
5D05 Ground Time Overcurrent 1 Multiplier 0 to 600 --- 0.01 F001 100
5D06 Ground Time Overcurrent 1 Reset 0 to 1 --- 1 F104 0 (Instantaneous)
5D07 Ground Time Overcurrent 1 Block 0 to 65535 --- 1 F300 0
5D08 Ground Time Overcurrent 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
5D09 Ground Time Overcurrent 1 Events 0 to 1 --- 1 F102 0 (Disabled)
5D0A Reserved (6 items) 0 to 1 --- 1 F001 0
5D10 ...Repeated for Ground Time Overcurrent 2
5D20 ...Repeated for Ground Time Overcurrent 3
5D30 ...Repeated for Ground Time Overcurrent 4
5D40 ...Repeated for Ground Time Overcurrent 5
5D50 ...Repeated for Ground Time Overcurrent 6
Ground Instantaneous Overcurrent (Read/Write Grouped Setting) (12 modules)
5E00 Ground Instantaneous Overcurrent 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
5E01 Ground Instantaneous Overcurrent 1 Function 0 to 1 --- 1 F102 0 (Disabled)
5E02 Ground Instantaneous Overcurrent 1 Pickup 0 to 30 pu 0.001 F001 1000
5E03 Ground Instantaneous Overcurrent 1 Delay 0 to 600 s 0.01 F001 0
5E04 Ground Instantaneous Overcurrent 1 Reset Delay 0 to 600 s 0.01 F001 0
5E05 Ground Instantaneous Overcurrent 1 Block 0 to 65535 --- 1 F300 0
5E06 Ground Instantaneous Overcurrent 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
5E07 Ground Instantaneous Overcurrent 1 Events 0 to 1 --- 1 F102 0 (Disabled)
5E08 Reserved (8 items) 0 to 1 --- 1 F001 0
5E10 ...Repeated for Ground Instantaneous Overcurrent 2
5E20 ...Repeated for Ground Instantaneous Overcurrent 3
5E30 ...Repeated for Ground Instantaneous Overcurrent 4
5E40 ...Repeated for Ground Instantaneous Overcurrent 5
5E50 ...Repeated for Ground Instantaneous Overcurrent 6
5E60 ...Repeated for Ground Instantaneous Overcurrent 7
5E70 ...Repeated for Ground Instantaneous Overcurrent 8
5E80 ...Repeated for Ground Instantaneous Overcurrent 9
5E90 ...Repeated for Ground Instantaneous Overcurrent 10
5EA0 ...Repeated for Ground Instantaneous Overcurrent 11
5EB0 ...Repeated for Ground Instantaneous Overcurrent 12
Frequency Out-Of-Band Accumulation (Read/Write Setting)
5F40 Frequency Out-Of-Band Accumulation Block 0 to 65535 --- 1 F300 0
5F41 Frequency Out-Of-Band Accumulation Events 0 to 1 --- 1 F102 0 (Disabled)
5F42 Frequency Out-Of-Band Accumulator 1 Function 0 to 1 --- 1 F102 0 (Disabled)
5F43 Frequency Out-Of-Band Accumulator 2 Function 0 to 1 --- 1 F102 0 (Disabled)
5F44 Frequency Out-Of-Band Accumulator 3 Function 0 to 1 --- 1 F102 0 (Disabled)
5F45 Frequency Out-Of-Band Accumulator 4 Function 0 to 1 --- 1 F102 0 (Disabled)
5F46 Frequency Out-Of-Band Accumulator 5 Function 0 to 1 --- 1 F102 0 (Disabled)
5F47 Frequency Out-Of-Band Accumulator 6 Function 0 to 1 --- 1 F102 0 (Disabled)
5F48 Frequency Out-Of-Band Accumulator 7 Function 0 to 1 --- 1 F102 0 (Disabled)
5F49 Frequency Out-Of-Band Accumulator 1 Lower Frequency 20.00 to 70.00 Hz 0.01 F001 6000
5F4A Frequency Out-Of-Band Accumulator 2 Lower Frequency 20.00 to 70.00 Hz 0.01 F001 6000
5F4B Frequency Out-Of-Band Accumulator 3 Lower Frequency 20.00 to 70.00 Hz 0.01 F001 6000
5F4C Frequency Out-Of-Band Accumulator 4 Lower Frequency 20.00 to 70.00 Hz 0.01 F001 6000
5F4D Frequency Out-Of-Band Accumulator 5 Lower Frequency 20.00 to 70.00 Hz 0.01 F001 6000
5F4E Frequency Out-Of-Band Accumulator 6 Lower Frequency 20.00 to 70.00 Hz 0.01 F001 6000
5F4F Frequency Out-Of-Band Accumulator 7 Lower Frequency 20.00 to 70.00 Hz 0.01 F001 6000
5F50 Frequency OOB Accumulation Minimum Volts/Amps 0.10 to 1.25 pu 0.01 F001 10
5F51 Frequency Out-Of-Band Accumulation Source 0 to 5 --- 1 F167 0 (SRC 1)
5F52 Frequency Out-Of-Band Accumulation Target 0 to 2 --- 1 F109 0 (Self-reset)
5F53 Frequency Out-Of-Band Accumulator 1 Time Limit 1 to 65535 s 1 F001 200
Table B–9: MODBUS MEMORY MAP (Sheet 21 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
