GE Multilin G60 Generator Protection System B-29
APPENDIX B B.4 MEMORY MAPPING
B
5F54 Frequency Out-Of-Band Accumulator 2 Time Limit 1 to 65535 s 1 F001 200
5F55 Frequency Out-Of-Band Accumulator 3 Time Limit 1 to 65535 s 1 F001 200
5F56 Frequency Out-Of-Band Accumulator 4 Time Limit 1 to 65535 s 1 F001 200
5F57 Frequency Out-Of-Band Accumulator 5 Time Limit 1 to 65535 s 1 F001 200
5F58 Frequency Out-Of-Band Accumulator 6 Time Limit 1 to 65535 s 1 F001 200
5F59 Frequency Out-Of-Band Accumulator 7 Time Limit 1 to 65535 s 1 F001 200
5F5A Frequency Out-Of-Band Accumulator 1 Time Preset 0 to 65535 s 1 F001 0
5F5B Frequency Out-Of-Band Accumulator 2 Time Preset 0 to 65535 s 1 F001 0
5F5C Frequency Out-Of-Band Accumulator 3 Time Preset 0 to 65535 s 1 F001 0
5F5D Frequency Out-Of-Band Accumulator 4 Time Preset 0 to 65535 s 1 F001 0
5F5E Frequency Out-Of-Band Accumulator 5 Time Preset 0 to 65535 s 1 F001 0
5F5F Frequency Out-Of-Band Accumulator 6 Time Preset 0 to 65535 s 1 F001 0
5F60 Frequency Out-Of-Band Accumulator 7 Time Preset 0 to 65535 s 1 F001 0
5F61 Frequency Out-Of-Band Accumulator 1 Upper Frequency 20.00 to 70.00 Hz 0.01 F001 6000
5F62 Frequency Out-Of-Band Accumulator 2 Upper Frequency 20.00 to 70.00 Hz 0.01 F001 6000
5F63 Frequency Out-Of-Band Accumulator 3 Upper Frequency 20.00 to 70.00 Hz 0.01 F001 6000
5F64 Frequency Out-Of-Band Accumulator 4 Upper Frequency 20.00 to 70.00 Hz 0.01 F001 6000
5F65 Frequency Out-Of-Band Accumulator 5 Upper Frequency 20.00 to 70.00 Hz 0.01 F001 6000
5F66 Frequency Out-Of-Band Accumulator 6 Upper Frequency 20.00 to 70.00 Hz 0.01 F001 6000
5F67 Frequency Out-Of-Band Accumulator 7 Upper Frequency 20.00 to 70.00 Hz 0.01 F001 6000
Setting Groups (Read/Write Setting)
5F80 Setting Group for Modbus Comms (0 means group 1) 0 to 5 --- 1 F001 0
5F81 Setting Groups Block 0 to 65535 --- 1 F300 0
5F82 FlexLogic to Activate Groups 2 through 6 (5 items) 0 to 65535 --- 1 F300 0
5F89 Setting Group Function 0 to 1 --- 1 F102 0 (Disabled)
5F8A Setting Group Events 0 to 1 --- 1 F102 0 (Disabled)
Setting Groups (Read Only)
5F8B Current Setting Group 0 to 5 --- 1 F001 0
Setting Group Names (Read/Write Setting)
5F8C Setting Group 1 Name --- --- --- F203 (none)
5F94 Setting Group 2 Name --- --- --- F203 (none)
5F9C Setting Group 3 Name --- --- --- F203 (none)
5FA4 Setting Group 4 Name --- --- --- F203 (none)
5FAC Setting Group 5 Name --- --- --- F203 (none)
5FB4 Setting Group 6 Name --- --- --- F203 (none)
Stator Differential (Read/Write Grouped Setting)
6470 Stator Differential Function 0 to 1 --- 1 F102 0 (Disabled)
6471 Stator Differential Pickup 0.05 to 1 pu 0.001 F001 100
6472 Stator Differential Slope 1 1 to 100 % 1 F001 10
6473 Stator Differential Slope 2 1 to 100 % 1 F001 80
6474 Stator Differential Break 1 1 to 1.5 pu 0.01 F001 115
6475 Stator Differential Break 2 1.5 to 30 pu 0.01 F001 800
6476 Stator Differential Block 0 to 65535 --- 1 F300 0
6477 Stator Differential Targets 0 to 2 --- 1 F109 0 (Self-reset)
6478 Stator Differential Events 0 to 1 --- 1 F102 0 (Disabled)
6479 Stator Differential Line End Source 0 to 5 --- 1 F167 0 (SRC 1)
647A Stator Differential Neutral End Source 0 to 5 --- 1 F167 0 (SRC 1)
Negative Sequence Overvoltage (Read/Write Grouped Setting)
64A0 Negative Sequence Overvoltage Function 0 to 1 --- 1 F102 0 (Disabled)
64A1 Negative Sequence Overvoltage Source 0 to 5 --- 1 F167 0 (SRC 1)
64A2 Negative Sequence Overvoltage Pickup 0 to 1.25 pu 0.001 F001 300
64A3 Negative Sequence Overvoltage Pickup Delay 0 to 600 s 0.01 F001 50
64A4 Negative Sequence Overvoltage Reset Delay 0 to 600 s 0.01 F001 50
64A5 Negative Sequence Overvoltage Block 0 to 65535 --- 1 F300 0
Table B–9: MODBUS MEMORY MAP (Sheet 22 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
