GE Multilin g60

B-30 G60 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
64A6 Negative Sequence Overvoltage Target 0 to 2 --- 1 F109 0 (Self-reset)
64A7 Negative Sequence Overvoltage Events 0 to 1 --- 1 F102 0 (Disabled)
Overfrequency (Read/Write Setting) (4 modules)
64D0 Overfrequency 1 Function 0 to 1 --- 1 F102 0 (Disabled)
64D1 Overfrequency 1 Block 0 to 65535 --- 1 F300 0
64D2 Overfrequency 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
64D3 Overfrequency 1 Pickup 20 to 65 Hz 0.01 F001 6050
64D4 Overfrequency 1 Pickup Delay 0 to 65.535 s 0.001 F001 500
64D5 Overfrequency 1 Reset Delay 0 to 65.535 s 0.001 F001 500
64D6 Overfrequency 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
64D7 Overfrequency 1 Events 0 to 1 --- 1 F102 0 (Disabled)
64D8 Reserved (4 items) 0 to 1 --- 1 F001 0
64DC ...Repeated for Overfrequency 2
64E8 ...Repeated for Overfrequency 3
64F4 ...Repeated for Overfrequency 4
Power Swing Detect (Read/Write Grouped Setting)
65C0 Power Swing Detect Function 0 to 1 --- 1 F102 0 (Disabled)
65C1 Power Swing Detect Source 0 to 5 --- 1 F167 0 (SRC 1)
65C2 Power Swing Detect Mode 0 to 1 --- 1 F513 0 (Two Step)
65C3 Power Swing Detect Supervision 0.05 to 30 pu 0.001 F001 600
65C4 Power Swing Detect Forward Reach 0.1 to 500 ohms 0.01 F001 5000
65C5 Power Swing Detect Forward RCA 40 to 90 degrees 1 F001 75
65C6 Power Swing Detect Reverse Reach 0.1 to 500 ohms 0.01 F001 5000
65C7 Power Swing Detect Reverse RCA 40 to 90 degrees 1 F001 75
65C8 Power Swing Detect Outer Limit Angle 40 to 140 degrees 1 F001 120
65C9 Power Swing Detect Middle Limit Angle 40 to 140 degrees 1 F001 90
65CA Power Swing Detect Inner Limit Angle 40 to 140 degrees 1 F001 60
65CB Power Swing Detect Delay 1 Pickup 0 to 65.535 s 0.001 F001 30
65CC Power Swing Detect Delay 1 Reset 0 to 65.535 s 0.001 F001 50
65CD Power Swing Detect Delay 2 Pickup 0 to 65.535 s 0.001 F001 17
65CE Power Swing Detect Delay 3 Pickup 0 to 65.535 s 0.001 F001 9
65CF Power Swing Detect Delay 4 Pickup 0 to 65.535 s 0.001 F001 17
65D0 Power Swing Detect Seal In Delay 0 to 65.535 s 0.001 F001 400
65D1 Power Swing Detect Trip Mode 0 to 1 --- 1 F514 0 (Delayed)
65D2 Power Swing Detect Block 0 to 65535 --- 1 F300 0
65D3 Power Swing Detect Target 0 to 2 --- 1 F109 0 (Self-reset)
65D4 Power Swing Detect Event 0 to 1 --- 1 F102 0 (Disabled)
65D5 Power Swing Detect Shape 0 to 1 --- 1 F085 0 (Mho Shape)
65D6 Power Swing Detect Quad Forward Middle 0.1 to 500 ohms 0.01 F001 6000
65D7 Power Swing Detect Quad Forward Outer 0.1 to 500 ohms 0.01 F001 7000
65D8 Power Swing Detect Quad Reverse Middle 0.1 to 500 ohms 0.01 F001 6000
65D9 Power Swing Detect Quad Reverse Outer 0.1 to 500 ohms 0.01 F001 7000
65DA Power Swing Detect Outer Right Blinder 0.1 to 500 ohms 0.01 F001 10000
65DB Power Swing Detect Outer Left Blinder 0.1 to 500 ohms 0.01 F001 10000
65DC Power Swing Detect Middle Right Blinder 0.1 to 500 ohms 0.01 F001 10000
65DD Power Swing Detect Middle Left Blinder 0.1 to 500 ohms 0.01 F001 10000
65DE Power Swing Detect Inner Right Blinder 0.1 to 500 ohms 0.01 F001 10000
65DF Power Swing Detect Inner Left Blinder 0.1 to 500 ohms 0.01 F001 10000
Accidental Energization (Read/Write Grouped Setting)
6660 Accidental Energization Function 0 to 1 --- 1 F102 0 (Disabled)
6661 Accidental Energization Source 0 to 5 --- 1 F167 0 (SRC 1)
6662 Accidental Energization Arming Mode 0 to 1 --- 1 F193 0 (UV AND OFFLINE)
6663 Accidental Energization OC Pickup 0 to 3 --- 0.001 F003 300
6665 Accidental Energization UV Pickup 0 to 3 --- 0.001 F003 500
Table B–9: MODBUS MEMORY MAP (Sheet 23 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
