GE Multilin G60 Generator Protection System B-31
APPENDIX B B.4 MEMORY MAPPING
B
6667 Accidental Energization Offline 0 to 65535 --- 1 F300 0
6668 Accidental Energization Block 0 to 65535 --- 1 F300 0
6669 Accidental Energization Target 0 to 2 --- 1 F109 0 (Self-reset)
666A Accidental Energization Events 0 to 1 --- 1 F102 0 (Disabled)
666B Reserved (5 items) 0 to 65535 --- 1 F001 0
Loss of Excitation (Read/Write Grouped Setting)
6680 Loss Of Excitation Function 0 to 1 --- 1 F102 0 (Disabled)
6681 Loss Of Excitation Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
6682 Loss Of Excitation Center 1 0.1 to 300 ohm 0.01 F001 1000
6683 Loss Of Excitation Radius 1 0.1 to 300 ohm 0.01 F001 800
6684 Loss Of Excitation UV Supervision Enable 1 0 to 1 --- 1 F102 1 (Enabled)
6685 Loss Of Excitation Pickup Delay 1 0 to 65.535 s 0.001 F001 50
6686 Loss Of Excitation Center 2 0.1 to 300 ohm 0.01 F001 1200
6687 Loss Of Excitation Radius 2 0.1 to 300 ohm 0.01 F001 1000
6688 Loss Of Excitation UV Supervision Enable 2 0 to 1 --- 1 F102 1 (Enabled)
6689 Loss Of Excitation Pickup Delay 2 0 to 65.535 s 0.001 F001 500
668A Loss Of Excitation UV Supervision 0 to 1.25 pu 0.001 F001 700
668B Loss Of Excitation Block 0 to 65535 --- 1 F300 0
668C Loss Of Excitation Target 0 to 2 --- 1 F109 0 (Self-reset)
668D Loss Of Excitation Events 0 to 1 --- 1 F102 0 (Disabled)
668E Reserved (5 items) 0 to 65535 --- 1 F001 0
Sensitive Directional Power (Read/Write Grouped Setting) (2 modules)
66A0 Sensitive Directional Power 1 Function 0 to 1 --- 1 F102 0 (Disabled)
66A1 Sensitive Directional Power 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
66A2 Sensitive Directional Power 1 RCA 0 to 359 degrees 1 F001 0
66A3 Sensitive Directional Power 1 Calibration 0 to 0.95 degrees 0.05 F001 0
66A4 Sensitive Directional Power 1 STG1 SMIN -1.2 to 1.2 pu 0.001 F002 100
66A5 Sensitive Directional Power 1 STG1 Delay 0 to 600 s 0.01 F001 50
66A6 Sensitive Directional Power 1 STG2 SMIN -1.2 to 1.2 pu 0.001 F002 100
66A7 Sensitive Directional Power 1 STG2 Delay 0 to 600 s 0.01 F001 2000
66A8 Sensitive Directional Power 1 Block --- --- --- F001 0
66A9 Sensitive Directional Power 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
66AA Sensitive Directional Power 1 Events 0 to 1 --- 1 F102 0 (Disabled)
66AB Reserved (5 items) 0 to 65535 --- 1 F001 0
66B0 ...Repeated for Sensitive Directional Power 2
Third Harmonic Neutral Undervoltage (Read/Write Grouped Setting)
6730 Third Harmonic Neutral Undervoltage Function 0 to 1 --- 1 F102 0 (Disabled)
6731 Third Harmonic Neutral Undervoltage Pickup 0 to 30 pu 0.0001 F003 3000
6733 Third Harmonic Neutral Undervoltage Delay 0 to 600 s 0.01 F001 0
6734 Third Harmonic Neutral Undervoltage Max Power 0 to 30 pu 0.001 F003 200
6736 Third Harmonic Neutral Undervoltage Min Power 0 to 30 pu 0.001 F003 200
6738 Third Harmonic Neutral Undervoltage Volt Supervision 0 to 1.25 pu 0.001 F001 500
6739 Third Harmonic Neutral Undervoltage Block 0 to 65535 --- 1 F300 0
673A Third Harmonic Neutral Undervoltage Target 0 to 2 --- 1 F109 0 (Self-reset)
673B Third Harmonic Neutral Undervoltage Events 0 to 1 --- 1 F102 0 (Disabled)
673C Reserved (4 items) 0 to 65535 --- 1 F001 0
Generator Unbalance (Read/Write Grouped Setting)
6740 Generator Unbalance Function 0 to 1 --- 1 F102 0 (Disabled)
6741 Generator Unbalance Source 0 to 5 --- 1 F167 0 (SRC 1)
6742 Generator Unbalance Source 0 to 1.25 pu 0.001 F001 800
6743 Generator Unbalance Stage 1 Pickup 0 to 100 % 0.01 F001 800
6744 Generator Unbalance Stage 1 K value 0 to 100 --- 0.01 F001 100
6745 Generator Unbalance Stage 1 Tmin 0 to 50 s 0.001 F001 250
6746 Generator Unbalance Stage 1 Tmax 0 to 1000 s 0.1 F001 6000
Table B–9: MODBUS MEMORY MAP (Sheet 24 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
