6747 Generator Unbalance Stage 1 K Reset 0 to 1000 s 0.1 F001 2400
6748 Generator Unbalance Stage 2 Pickup 0 to 100 % 0.01 F001 300
6749 Generator Unbalance Stage 2 Pickup Delay 0 to 1000 s 0.1 F001 50
674A Generator Unbalance Block 0 to 65535 --- 1 F300 0
674B Generator Unbalance Target 0 to 2 --- 1 F109 0 (Self-reset)
674C Generator Unbalance Events 0 to 1 --- 1 F102 0 (Disabled)
674D Reserved (3 items) 0 to 65535 --- 1 F001 0
Stator Ground Source (Read/Write Grouped Setting)
6750 Stator Ground Source 0 to 5 --- 1 F167 0 (SRC 1)
Stator Ground (Read/Write Grouped Setting)
6780 Stator Ground Function 0 to 1 --- 1 F102 0 (Disabled)
6781 Stator Ground Stage 1 Pickup 0 to 0.900 pu 0.001 F001 150
6782 Stator Ground Stage 1 Pickup Delay 0 to 600 s 0.01 F001 100
6783 Stator Ground Stage 1 Supervision 0.001 to 0.100 pu 0.0001 F001 57
6784 Stator Ground Stage 2 Pickup 0 to 0.900 pu 0.001 F001 150
6785 Stator Ground Stage 2 Pickup Delay 0 to 600 s 0.01 F001 0
6786 Stator Ground Stage 2 Supervision 0.001 to 0.100 pu 0.0001 F001 45
6787 Stator Ground Block --- --- --- F001 0
6788 Stator Ground Target 0 to 2 --- 1 F109 0 (Self-reset)
6789 Stator Ground Event 0 to 1 --- 1 F102 0 (Disabled)
678A Reserved (5 items) 0 to 65535 --- 1 F001 0
Split Phase Protection (Read/Write Grouped Setting)
67A0 Split Phase Protection Function 0 to 1 --- 1 F102 0 (Disabled)
67A1 Split Phase Protection Source 0 to 5 --- 1 F167 0 (SRC1)
67A2 Split Phase Protection Load Source 0 to 5 --- 1 F167 0 (SRC1)
67A3 Split Phase Protection Phase A Pickup 0.020 to 1.500 pu 0.001 F001 200
67A4 Split Phase Protection Phase A Offset 0 to 1 pu 0.001 F001 0
67A5 Split Phase Protection Phase A Slope 0 to 100 % 0.1 F001 0
67A6 Split Phase Protection Phase B Pickup 0.020 to 1.500 pu 0.001 F001 200
67A7 Split Phase Protection Phase B Offset 0 to 1 pu 0.001 F001 0
67A8 Split Phase Protection Phase B Slope 0 to 100 % 0.1 F001 0
67A9 Split Phase Protection Phase C Pickup 0.020 to 1.500 pu 0.001 F001 200
67AA Split Phase Protection Phase C Offset 0 to 1 pu 0.001 F001 0
67AB Split Phase Protection Phase C Slope 0 to 100 % 0.1 F001 0
67AC Split Phase Protection Minimum Load 0 to 1 pu 0.01 F001 0
67AD Split Phase Protection Mode 0 to 1 --- 1 F225 0 (Over)
67AE Split Phase Protection Delay 0 to 65.535 s 0.001 F001 0
67AF Split Phase Protection Block 0 to 65535 --- 1 F300 0
67B0 Split Phase Protection Target 0 to 2 --- 1 F109 0 (Self-Reset)
67B1 Split Phase Protection Events 0 to 1 --- 1 F102 0 (Disabled)
67B2 Reserved (6 items) 0 to 65535 --- 1 F001 0
Phase Undervoltage (Read/Write Grouped Setting) (2 modules)
7000 Phase Undervoltage 1 Function 0 to 1 --- 1 F102 0 (Disabled)
7001 Phase Undervoltage 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
7002 Phase Undervoltage 1 Pickup 0 to 3 pu 0.001 F001 1000
7003 Phase Undervoltage 1 Curve 0 to 1 --- 1 F111 0 (Definite Time)
7004 Phase Undervoltage 1 Delay 0 to 600 s 0.01 F001 100
7005 Phase Undervoltage 1 Minimum Voltage 0 to 3 pu 0.001 F001 100
7006 Phase Undervoltage 1 Block 0 to 65535 --- 1 F300 0
7007 Phase Undervoltage 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7008 Phase Undervoltage 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7009 Phase Undervoltage 1 Measurement Mode 0 to 1 --- 1 F186 0 (Phase to Ground)
700A Reserved (6 items) 0 to 1 --- 1 F001 0
7013 ...Repeated for Phase Undervoltage 2
Table B–9: MODBUS MEMORY MAP (Sheet 25 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
