GE Multilin G60 Generator Protection System B-33
APPENDIX B B.4 MEMORY MAPPING
B
Phase Overvoltage (Read/Write Grouped Setting)
7040 Phase Overvoltage 1 Function 0 to 1 --- 1 F102 0 (Disabled)
7041 Phase Overvoltage 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
7042 Phase Overvoltage 1 Pickup 0 to 3 pu 0.001 F001 1000
7043 Phase Overvoltage 1 Delay 0 to 600 s 0.01 F001 100
7044 Phase Overvoltage 1 Reset Delay 0 to 600 s 0.01 F001 100
7045 Phase Overvoltage 1 Block 0 to 65535 --- 1 F300 0
7046 Phase Overvoltage 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7047 Phase Overvoltage 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7048 Reserved (8 items) 0 to 1 --- 1 F001 0
Distance (Read/Write Grouped Setting)
7060 Distance Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
7061 Memory Duration 5 to 25 cycles 1 F001 10
7062 Force Self-Polarization 0 to 65535 --- 1 F300 0
7062 Force Memory Polarization 0 to 65535 --- 1 F300 0
Phase Distance (Read/Write Grouped Setting) (5 modules)
7070 Phase Distance Zone 1 Function 0 to 1 --- 1 F102 0 (Disabled)
7071 Phase Distance Zone 1 Current Supervision 0.05 to 30 pu 0.001 F001 200
7072 Phase Distance Zone 1 Reach 0.02 to 500 ohms 0.01 F001 200
7073 Phase Distance Zone 1 Direction 0 to 2 --- 1 F154 0 (Forward)
7074 Phase Distance Zone 1 Comparator Limit 30 to 90 degrees 1 F001 90
7075 Phase Distance Zone 1 Delay 0 to 65.535 s 0.001 F001 0
7076 Phase Distance Zone 1 Block 0 to 65535 --- 1 F300 0
7077 Phase Distance Zone 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7078 Phase Distance Zone 1 Events 0 to 1 --- 1 F102 0 (Disabled)
707A Phase Distance Zone 1 RCA 30 to 90 degrees 1 F001 85
707B Phase Distance Zone 1 DIR RCA 30 to 90 degrees 1 F001 85
707C Phase Distance Zone 1 DIR Comp Limit 30 to 90 degrees 1 F001 90
7081 Phase Distance Zone 1 Volt Limit 0 to 5 pu 0.001 F001 0
7082 Phase Distance Zone 1 Transformer Voltage Connection 0 to 12 --- 1 F153 0 (None)
7083 Phase Distance Zone 1 Transformer Current Connection 0 to 12 --- 1 F153 0 (None)
7084 Phase Distance Zone 1 Rev Reach 0.02 to 500 ohms 0.01 F001 200
7085 Phase Distance Zone 1 Rev Reach RCA 30 to 90 degrees 1 F001 85
7086 Reserved (10 items) --- --- --- F001 0
7090 ...Repeated for Phase Distance Zone 2
70B0 ...Repeated for Phase Distance Zone 3
Phase Directional Overcurrent (Read/Write Grouped Setting) (2 modules)
7260 Phase Directional Overcurrent 1 Function 0 to 1 --- 1 F102 0 (Disabled)
7261 Phase Directional Overcurrent 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
7262 Phase Directional Overcurrent 1 Block 0 to 65535 --- 1 F300 0
7263 Phase Directional Overcurrent 1 ECA 0 to 359 --- 1 F001 30
7264 Phase Directional Overcurrent 1 Pol V Threshold 0 to 3 pu 0.001 F001 700
7265 Phase Directional Overcurrent 1 Block Overcurrent 0 to 1 --- 1 F126 0 (No)
7266 Phase Directional Overcurrent 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7267 Phase Directional Overcurrent 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7268 Reserved (8 items) 0 to 1 --- 1 F001 0
7270 ...Repeated for Phase Directional Overcurrent 2
Neutral Directional Overcurrent (Read/Write Grouped Setting) (2 modules)
7280 Neutral Directional Overcurrent 1 Function 0 to 1 --- 1 F102 0 (Disabled)
7281 Neutral Directional Overcurrent 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
7282 Neutral Directional Overcurrent 1 Polarizing 0 to 2 --- 1 F230 0 (Voltage)
7283 Neutral Directional Overcurrent 1 Forward ECA -90 to 90 ° Lag 1 F002 75
7284 Neutral Directional Overcurrent 1 Forward Limit Angle 40 to 90 degrees 1 F001 90
7285 Neutral Directional Overcurrent 1 Forward Pickup 0.002 to 30 pu 0.001 F001 50
Table B–9: MODBUS MEMORY MAP (Sheet 26 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
