B-36 G60 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
7861 PMU 1 Power Trigger Active 0.25 to 3 pu 0.001 F001 1250
7862 PMU 1 Power Trigger Reactive 0.25 to 3 pu 0.001 F001 1250
7863 PMU 1 Power Trigger Apparent 0.25 to 3 pu 0.001 F001 1250
7864 PMU 1 Power Trigger Pickup Time 0 to 600 s 0.01 F001 10
7865 PMU 1 Power Trigger Dropout Time 0 to 600 s 0.01 F001 100
7866 PMU 1 Power Trigger Block (3 items) 0 to 65535 --- 1 F300 0
7869 PMU 1 Power Trigger Target 0 to 2 --- 1 F109 0 (Self-reset)
786A PMU 1 Power Trigger Events 0 to 1 --- 1 F102 0 (Disabled)
786B ...Repeated for PMU 2
7876 ...Repeated for PMU 3
7881 ...Repeated for PMU 4
Phasor Measurement Unit Voltage Trigger (Read/Write Setting)
788C PMU 1 Voltage Trigger Function 0 to 1 --- 1 F102 0 (Disabled)
788D PMU 1 Voltage Trigger Low Voltage 0.25 to 1.25 pu 0.001 F001 800
788E PMU 1 Voltage Trigger High Voltage 0.75 to 1.75 pu 0.001 F001 1200
788F PMU 1 Voltage Trigger Pickup Time 0 to 600 s 0.01 F001 10
7890 PMU 1 Voltage Trigger Dropout Time 0 to 600 s 0.01 F001 100
7891 PMU 1 Voltage Trigger Block (3 items) 0 to 65535 --- 1 F300 0
7894 PMU 1 Voltage Trigger Target 0 to 2 --- 1 F109 0 (Self-reset)
7895 PMU 1 Voltage Trigger Events 0 to 1 --- 1 F102 0 (Disabled)
Phasor Measurement Unit One-shot Command (Read/Write Setting)
78B4 PMU One-shot Function 0 to 1 --- 1 F102 0 (Disabled)
78B5 PMU One-shot Sequence Number 0 to 99 --- 1 F001 1
78B6 PMU One-shot Time 0 to 235959 --- 1 F050 0
Phasor Measurement Unit Test Values (Read/Write Setting)
78B8 PMU 1 Test Function 0 to 1 --- 1 F102 0 (Disabled)
78B9 PMU 1 Phase A Voltage Test Magnitude 0 to 700 kV 0.01 F003 50000
78BB PMU 1 Phase A Voltage Test Angle -180 to 180 ° 0.05 F002 0
78BC PMU 1 Phase B Voltage Test Magnitude 0 to 700 kV 0.01 F003 50000
78BE PMU 1 Phase B Voltage Test Angle -180 to 180 ° 0.05 F002 -120
78BF PMU 1 Phase C Voltage Test Magnitude 0 to 700 kV 0.01 F003 50000
78C1 PMU 1 Phase C Voltage Test Angle -180 to 180 ° 0.05 F002 120
78C2 PMU 1 Auxiliary Voltage Test Magnitude 0 to 700 kV 0.01 F003 50000
78C4 PMU 1 Auxiliary Voltage Test Angle -180 to 180 ° 0.05 F002 0
78C5 PMU 1 Phase A Current Test Magnitude 0 to 9.999 kA 0.001 F004 1000
78C7 PMU 1 Phase A Current Test Angle -180 to 180 ° 0.05 F002 -10
78C8 PMU 1 Phase B Current Test Magnitude 0 to 9.999 kA 0.001 F004 1000
78CA PMU 1 Phase B Current Test Angle -180 to 180 ° 0.05 F002 -130
78CB PMU 1 Phase C Current Test Magnitude 0 to 9.999 kA 0.001 F003 1000
78CD PMU 1 Phase C Current Test Angle -180 to 180 ° 0.05 F002 110
78CE PMU 1 Ground Current Test Magnitude 0 to 9.999 kA 0.001 F004 0
78D0 PMU 1 Ground Current Test Angle -180 to 180 ° 0.05 F002 0
78D1 PMU 1 Test Frequency 20 to 70 Hz 0.001 F003 60000
78D3 PMU 1 Test df/dt -10 to 10 Hz/s 0.01 F002 0
Phasor Measurement Unit Recorder Configuration Counter Command (Read/Write Command)
7928 PMU 1 Recorder Clear Configuration Counter 0 to 1 --- 1 F126 0 (No)
Phasor Measurement Unit Recording Values (Read Only)
792C PMU 1 Available Records 0 to 65535 --- 1 F001 0
792D PMU 1 Second Per Record 0 to 6553.5 --- 0.1 F001 0
792F PMU 1 Last Cleared Date 0 to 400000000 --- 1 F050 0
Phasor Measurement Unit Network Reporting Configuration (Read/Write Setting)
7940 PMU Network Reporting Function 0 to 1 --- 1 F102 0 (Disabled)
7941 PMU Network Reporting ID Code 1 to 65534 --- 1 F001 1
7946 PMU TCP port number 1 to 65535 --- 1 F001 4712
Table B–9: MODBUS MEMORY MAP (Sheet 29 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
