GE Multilin g60

B-40 G60 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
7F35 Auxiliary Overvoltage 1 Block 0 to 65535 --- 1 F300 0
7F36 Auxiliary Overvoltage 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7F37 Auxiliary Overvoltage 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7F38 Reserved (8 items) 0 to 65535 --- 1 F001 0
7F40 ...Repeated for Auxiliary Overvoltage 2
7F50 ...Repeated for Auxiliary Overvoltage 3
Auxiliary Undervoltage (Read/Write Grouped Setting) (3 modules)
7F60 Auxiliary Undervoltage 1 Function 0 to 1 --- 1 F102 0 (Disabled)
7F61 Auxiliary Undervoltage 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
7F62 Auxiliary Undervoltage 1 Pickup 0 to 3 pu 0.001 F001 700
7F63 Auxiliary Undervoltage 1 Delay 0 to 600 s 0.01 F001 100
7F64 Auxiliary Undervoltage 1 Curve 0 to 1 --- 1 F111 0 (Definite Time)
7F65 Auxiliary Undervoltage 1 Minimum Voltage 0 to 3 pu 0.001 F001 100
7F66 Auxiliary Undervoltage 1 Block 0 to 65535 --- 1 F300 0
7F67 Auxiliary Undervoltage 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7F68 Auxiliary Undervoltage 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7F69 Reserved (7 items) 0 to 65535 --- 1 F001 0
7F70 ...Repeated for Auxiliary Undervoltage 2
7F80 ...Repeated for Auxiliary Undervoltage 3
Frequency (Read Only)
8000 Tracking Frequency --- Hz --- F001 0
EGD Fast Production Status (Read Only)
83E0 EGD Fast Producer Exchange 1 Signature 0 to 65535 --- 1 F001 0
83E1 EGD Fast Producer Exchange 1 Configuration Time 0 to 4294967295 --- --- F003 0
83E3 EGD Fast Producer Exchange 1 Size 0 to 65535 --- 1 F001 0
EGD Slow Production Status (Read Only) (2 modules)
83F0 EGD Slow Producer Exchange 1 Signature 0 to 65535 --- 1 F001 0
83F1 EGD Slow Producer Exchange 1 Configuration Time 0 to 4294967295 --- --- F003 0
83F3 EGD Slow Producer Exchange 1 Size 0 to 65535 --- 1 F001 0
83F4 ...Repeated for module number 2
EGD Fast Production (Read/Write Setting)
8400 EGD Fast Producer Exchange 1 Function 0 to 1 --- 1 F102 0 (Disabled)
8401 EGD Fast Producer Exchange 1 Destination 0 to 4294967295 --- 1 F003 0
8403 EGD Fast Producer Exchange 1 Data Rate 50 to 1000 ms 50 F001 1000
8404 EGD Fast Producer Exchange 1 Data Item 1 (20 items) 0 to 65535 --- 1 F001 0
8418 Reserved (80 items) --- --- --- F001 0
EGD Slow Production (Read/Write Setting) (2 modules)
8500 EGD Slow Producer Exchange 1 Function 0 to 1 --- 1 F102 0 (Disabled)
8501 EGD Fast Producer Exchange 1 Destination 0 to 4294967295 --- 1 F003 0
8503 EGD Slow Producer Exchange 1 Data Rate 500 to 1000 ms 50 F001 1000
8504 EGD Slow Producer Exchange 1 Data Item 1 (50 items) 0 to 65535 --- 1 F001 0
8536 Reserved (50 items) --- --- --- F001 0
8568 ...Repeated for EGD Exchange 2
Remote RTD inputs (Read/Write Grouped Setting) (12 modules)
86D0 Remote RTD 1 Function 0 to 1 --- 1 F102 0 (Disabled)
86D1 Remote RTD 1 ID --- --- --- F205 "RRTD 1"
86D7 Remote RTD 1 Type 0 to 3 --- 1 F174 0 (100 ohm Platinum)
86D8 Remote RTD 1 Application 0 to 5 --- 1 F550 0 (None)
86D9 Remote RTD 1 Alarm Temperature 1 to 200 °C 1 F001 130
86DA Remote RTD 1 Alarm Pickup Delay 5 to 600 seconds 5 F001 5
86DB Remote RTD 1 Trip Temperature 1 to 200 °C 1 F001 130
86DC Remote RTD 1 Trip Pickup Delay 5 to 600 seconds 5 F001 5
86DD Remote RTD 1 Trip Reset Delay 5 to 600 seconds 5 F001 5
86DE Remote RTD 1 Trip Voting 0 to 13 --- 1 F603 0 (None)
Table B–9: MODBUS MEMORY MAP (Sheet 33 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
