GE Multilin G60 Generator Protection System B-39
APPENDIX B B.4 MEMORY MAPPING
B
7B87 User Programmable Pushbutton 1 Remote Lock 0 to 65535 --- 1 F300 0
7B88 User Programmable Pushbutton 1 Reset 0 to 65535 --- 1 F300 0
7B89 User Programmable Pushbutton 1 Set 0 to 65535 --- 1 F300 0
7B8A User Programmable Pushbutton 1 Hold 0 to 10 s 0.1 F001 1
7B8B ...Repeated for User Programmable Pushbutton 2
7BB6 ...Repeated for User Programmable Pushbutton 3
7BE1 ...Repeated for User Programmable Pushbutton 4
7C0C ...Repeated for User Programmable Pushbutton 5
7C37 ...Repeated for User Programmable Pushbutton 6
7C62 ...Repeated for User Programmable Pushbutton 7
7C8D ...Repeated for User Programmable Pushbutton 8
7CB8 ...Repeated for User Programmable Pushbutton 9
7CE3 ...Repeated for User Programmable Pushbutton 10
7D0E ...Repeated for User Programmable Pushbutton 11
7D39 ...Repeated for User Programmable Pushbutton 12
7D64 ...Repeated for User Programmable Pushbutton 13
7D8F ...Repeated for User Programmable Pushbutton 14
7DBA ...Repeated for User Programmable Pushbutton 15
7DE5 ...Repeated for User Programmable Pushbutton 16
Underfrequency (Read/Write Setting) (6 modules)
7E10 Underfrequency Function 0 to 1 --- 1 F102 0 (Disabled)
7E11 Underfrequency 1 Block 0 to 65535 --- 1 F300 0
7E12 Underfrequency 1 Minimum Current 0.1 to 1.25 pu 0.01 F001 10
7E13 Underfrequency 1 Pickup 20 to 65 Hz 0.01 F001 5950
7E14 Underfrequency 1 Pickup Delay 0 to 65.535 s 0.001 F001 2000
7E15 Underfrequency 1 Reset Delay 0 to 65.535 s 0.001 F001 2000
7E16 Underfrequency 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
7E17 Underfrequency 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7E18 Underfrequency 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7E19 Reserved (8 items) 0 to 1 --- 1 F001 0
7E21 ...Repeated for Underfrequency 2
7E32 ...Repeated for Underfrequency 3
7E43 ...Repeated for Underfrequency 4
7E54 ...Repeated for Underfrequency 5
7E65 ...Repeated for Underfrequency 6
Neutral Overvoltage (Read/Write Grouped Setting) (3 modules)
7F00 Neutral Overvoltage 1 Function 0 to 1 --- 1 F102 0 (Disabled)
7F01 Neutral Overvoltage 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
7F02 Neutral Overvoltage 1 Pickup 0 to 3.00 pu 0.001 F001 300
7F03 Neutral Overvoltage 1 Pickup Delay 0 to 600 s 0.01 F001 100
7F04 Neutral Overvoltage 1 Reset Delay 0 to 600 s 0.01 F001 100
7F05 Neutral Overvoltage 1 Block 0 to 65535 --- 1 F300 0
7F06 Neutral Overvoltage 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
7F07 Neutral Overvoltage 1 Events 0 to 1 --- 1 F102 0 (Disabled)
7F08 Neutral Overvoltage 1 Curves 0 to 3 --- 1 F116 0 (Definite Time)
7F09 Reserved (8 items) 0 to 65535 --- 1 F001 0
7F10 ...Repeated for Neutral Overvoltage 2
7F20 ...Repeated for Neutral Overvoltage 3
Auxiliary Overvoltage (Read/Write Grouped Setting) (3 modules)
7F30 Auxiliary Overvoltage 1 Function 0 to 1 --- 1 F102 0 (Disabled)
7F31 Auxiliary Overvoltage 1 Signal Source 0 to 5 --- 1 F167 0 (SRC 1)
7F32 Auxiliary Overvoltage 1 Pickup 0 to 3 pu 0.001 F001 300
7F33 Auxiliary Overvoltage 1 Pickup Delay 0 to 600 s 0.01 F001 100
7F34 Auxiliary Overvoltage 1 Reset Delay 0 to 600 s 0.01 F001 100
Table B–9: MODBUS MEMORY MAP (Sheet 32 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
