GE Multilin G60 Generator Protection System B-45
APPENDIX B B.4 MEMORY MAPPING
B
9913 ...Repeated for IEC61850 GOOSE UInteger 2
9916 ...Repeated for IEC61850 GOOSE UInteger 3
9919 ...Repeated for IEC61850 GOOSE UInteger 4
991C ...Repeated for IEC61850 GOOSE UInteger 5
991F ...Repeated for IEC61850 GOOSE UInteger 6
9922 ...Repeated for IEC61850 GOOSE UInteger 7
9925 ...Repeated for IEC61850 GOOSE UInteger 8
9928 ...Repeated for IEC61850 GOOSE UInteger 9
992B ...Repeated for IEC61850 GOOSE UInteger 10
992E ...Repeated for IEC61850 GOOSE UInteger 11
9931 ...Repeated for IEC61850 GOOSE UInteger 12
9934 ...Repeated for IEC61850 GOOSE UInteger 13
9937 ...Repeated for IEC61850 GOOSE UInteger 14
993A ...Repeated for IEC61850 GOOSE UInteger 15
993D ...Repeated for IEC61850 GOOSE UInteger 16
FlexElement Actuals (Read Only) (16 modules)
9A01 FlexElement™ 1 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9A03 FlexElement™ 2 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9A05 FlexElement™ 3 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9A07 FlexElement™ 4 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9A09 FlexElement™ 5 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9A0B FlexElement™ 6 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9A0D FlexElement™ 7 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9A0F FlexElement™ 8 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9A11 FlexElement™ 9 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9A13 FlexElement™ 10 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9A15 FlexElement™ 11 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9A17 FlexElement™ 12 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9A19 FlexElement™ 13 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9A1B FlexElement™ 14 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9A1D FlexElement™ 15 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
9A1F FlexElement™ 16 Actual
-2147483.647 to 2147483.647
--- 0.001 F004 0
Teleprotection Inputs/Outputs (Read/Write Settings)
9B00 Teleprotection Function 0 to 1 --- 1 F102 0 (Disabled)
9B01 Teleprotection Number of Terminals 2 to 3 --- 1 F001 2
9B02 Teleprotection Number of Channels 1 to 2 --- 1 F001 1
9B03 Teleprotection Local Relay ID 0 to 255 --- 1 F001 0
9B04 Teleprotection Terminal 1 ID 0 to 255 --- 1 F001 0
9B05 Teleprotection Terminal 2 ID 0 to 255 --- 1 F001 0
9B06 Reserved (10 items) 0 to 1 --- --- F001 0
9B10 Teleprotection Input 1-n Default States (16 items) 0 to 3 --- 1 F086 0 (Off)
9B30 Teleprotection Input 2-n Default States (16 items) 0 to 3 --- 1 F086 0 (Off)
9B50 Teleprotection Output 1-n Operand (16 items) 0 to 65535 --- 1 F300 0
9B70 Teleprotection Output 2-n Operand (16 items) 0 to 65535 --- 1 F300 0
Teleprotection Inputs/Outputs Commands (Read/Write Command)
9B90 Teleprotection Clear Lost Packets 0 to 1 --- 1 F126 0 (No)
Teleprotection Channel Tests (Read Only)
9B91 Teleprotection Channel 1 Status 0 to 2 --- 1 F134 1 (OK)
9B92 Teleprotection Channel 1 Number of Lost Packets 0 to 65535 --- 1 F001 0
9B93 Teleprotection Channel 2 Status 0 to 2 --- 1 F134 1 (OK)
9B94 Teleprotection Channel 2 Number of Lost Packets 0 to 65535 --- 1 F001 0
9B95 Teleprotection Network Status 0 to 2 --- 1 F134 2 (n/a)
9BA0 Teleprotection Channel 1 Input States 0 to 1 --- 1 F500 0
9BA1 Teleprotection Channel 2 Input States 0 to 1 --- 1 F500 0
Table B–9: MODBUS MEMORY MAP (Sheet 38 of 59)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
