B-72 G60 Generator Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F125
ENUMERATION: ACCESS LEVEL
0 = Restricted; 1 = Command, 2 = Setting, 3 = Factory Service
F126
ENUMERATION: NO/YES CHOICE
0 = No, 1 = Yes
F127
ENUMERATION: LATCHED OR SELF-RESETTING
0 = Latched, 1 = Self-Reset
F128
ENUMERATION: CONTACT INPUT THRESHOLD
0 = 17 V DC, 1 = 33 V DC, 2 = 84 V DC, 3 = 166 V DC
F129
ENUMERATION: FLEXLOGIC TIMER TYPE
0 = millisecond, 1 = second, 2 = minute
F130
ENUMERATION: SIMULATION MODE
0 = Off. 1 = Pre-Fault, 2 = Fault, 3 = Post-Fault
F131
ENUMERATION: FORCED CONTACT OUTPUT STATE
0 = Disabled, 1 = Energized, 2 = De-energized, 3 = Freeze
F133
ENUMERATION: PROGRAM STATE
0 = Not Programmed, 1 = Programmed
F134
ENUMERATION: PASS/FAIL
0 = Fail, 1 = OK, 2 = n/a
F135
ENUMERATION: GAIN CALIBRATION
0 = 0x1, 1 = 1x16
F136
ENUMERATION: NUMBER OF OSCILLOGRAPHY RECORDS
0 = 31 x 8 cycles, 1 = 15 x 16 cycles, 2 = 7 x 32 cycles
3 = 3 x 64 cycles, 4 = 1 x 128 cycles
F137
ENUMERATION: USER-PROGRAMMABLE PUSHBUTTON
FUNCTION
0 = Disabled, 1 = Self-Reset, 2 = Latched
F138
ENUMERATION: OSCILLOGRAPHY FILE TYPE
0 = Data File, 1 = Configuration File, 2 = Header File
F140
ENUMERATION: CURRENT, SENS CURRENT, VOLTAGE,
DISABLED
0 = Disabled, 1 = Current 46 A, 2 = Voltage 280 V,
3 = Current 4.6 A, 4 = Current 2 A, 5 = Notched 4.6 A,
6 = Notched 2 A
F141
ENUMERATION: SELF TEST ERRORS
996 Remote RTD Input 6
997 Remote RTD Input 7
998 Remote RTD Input 8
999 Remote RTD Input 9
1000 Remote RTD Input 10
1001 Remote RTD Input 11
1002 Remote RTD Input 12
1012 Thermal overload protection 1
1013 Thermal overload protection 2
bitmask element
Bitmask Error
0 Any Self Tests
1 IRIG-B Failure
2 Port 1 Offline
3 Port 2 Offline
4 Port 3 Offline
5 Port 4 Offline
6 Port 5 Offline
7 Port 6 Offline
8 RRTD Communcations Failure
9 Voltage Monitor
10 FlexLogic Error Token
11 Equipment Mismatch
12 Process Bus Failure
13 Unit Not Programmed
14 System Exception
15 Latching Output Discrepancy
16 Ethernet Switch Fail
17 Maintenance Alert 01
18 SNTP Failure
19 ---
20 Primary Ethernet Fail
21 Secondary Ethernet Fail
