GE Multilin G60 Generator Protection System B-73
APPENDIX B B.4 MEMORY MAPPING
B
F142
ENUMERATION: EVENT RECORDER ACCESS FILE TYPE
0 = All Record Data, 1 = Headers Only, 2 = Numeric Event Cause
F143
UR_UINT32: 32 BIT ERROR CODE (F141 specifies bit number)
A bit value of 0 = no error, 1 = error
F144
ENUMERATION: FORCED CONTACT INPUT STATE
0 = Disabled, 1 = Open, 2 = Closed
F145
ENUMERATION: ALPHABET LETTER
F146
ENUMERATION: MISCELLANEOUS EVENT CAUSES
22 Temperature Monitor
23 Process Bus Trouble
24 Brick Trouble
25 Field RTD Trouble
26 Field TDR Trouble
27 Remote Device Offline
28 Direct Device Offline
29 Direct Input/Output Ring Break
30 Any Minor Error
31 Any Major Error
32 IEC 61850 Data Set
33 Aggregator Error
34 ---
35 ---
36 Watchdog Error
37 Low On Memory
38 ---
43 Module Failure 01
44 Module Failure 02
45 Module Failure 03
46 Module Failure 04
47 Module Failure 05
48 Module Failure 06
49 Module Failure 07
50 Module Failure 08
51 Module Failure 09
52 Incompatible Hardware
53 Module Failure 10
54 Module Failure 11
55 Module Failure 12
Bitmask Error
bitmask type bitmask type bitmask type bitmask type
0 null 7 G 14 N 21 U
1A 8H 15O 22V
2B 9 I 16P 23W
3 C 10 J 17 Q 24 X
4D 11K 18R 25Y
5 E 12 L 19 S 26 Z
6F 13M 20T
bitmask definition
0 Events Cleared
1 Oscillography Triggered
2 Date/time Changed
3 Default Settings Loaded
4 Test Mode Forcing On
5 Test Mode Forcing Off
6 Power On
7 Power Off
8 Relay In Service
9 Relay Out Of Service
10 Watchdog Reset
11 Oscillography Clear
12 Reboot Command
13 Led Test Initiated
14 Flash Programming
15 Fault Report Trigger
16 User Programmable Fault Report Trigger
17 ---
18 Reload CT/VT module Settings
19 ---
20 Ethernet Port 1 Offline
21 Ethernet Port 2 Offline
22 Ethernet Port 3 Offline
23 Ethernet Port 4 Offline
24 Ethernet Port 5 Offline
25 Ethernet Port 6 Offline
26 Test Mode Isolated
27 Test Mode Forcible
28 Test Mode Disabled
29 Temperature Warning On
30 Temperature Warning Off
31 Unauthorized Access
32 System Integrity Recovery
33 System Integrity Recovery 06
34 System Integrity Recovery 07
