GE Multilin G60 Generator Protection System B-81
APPENDIX B B.4 MEMORY MAPPING
B
F237
ENUMERATION: REAL TIME CLOCK MONTH
F238
ENUMERATION: REAL TIME CLOCK DAY
F239
ENUMERATION: REAL TIME CLOCK DAYLIGHT SAVINGS
TIME START DAY INSTANCE
F240
ENUMERATION: V/HZ CURVES
0 = Definite Time, 1 = Inverse A, 2 = Inverse B, 3 = Inverse C,
4 = FlexCurve™ A, 5 = FlexCurve™ B, 6 = FlexCurve™ C,
7 = FlexCurve™ D
F254
ENUMERATION: TEST MODE FUNCTION
F260
ENUMERATION: DATA LOGGER MODE
0 = Continuous, 1 = Trigger
F300
UR_UINT16: FLEXLOGIC™ BASE TYPE (6-bit type)
The FlexLogic™ BASE type is 6 bits and is combined with a 9 bit
descriptor and 1 bit for protection element to form a 16 bit value.
The combined bits are of the form: PTTTTTTDDDDDDDDD,
where P bit if set, indicates that the FlexLogic™ type is associated
with a protection element state and T represents bits for the BASE
type, and D represents bits for the descriptor.
The values in square brackets indicate the base type with P prefix
[PTTTTTT] and the values in round brackets indicate the descrip-
tor range.
[0] Off(0) – this is boolean FALSE value
[0] On (1) – this is boolean TRUE value
[2] CONTACT INPUTS (1 to 96)
[3] CONTACT INPUTS OFF (1 to 96)
[4] VIRTUAL INPUTS (1 to 64)
[6] VIRTUAL OUTPUTS (1 to 96)
[10] CONTACT OUTPUTS VOLTAGE DETECTED (1 to 64)
[11] CONTACT OUTPUTS VOLTAGE OFF DETECTED (1 to 64)
[12] CONTACT OUTPUTS CURRENT DETECTED (1 to 64)
[13] CONTACT OUTPUTS CURRENT OFF DETECTED (1 to 64)
[14] REMOTE INPUTS (1 to 32)
[28] INSERT (via keypad only)
[32] END
[34] NOT (1 INPUT)
[36] 2 INPUT XOR (0)
[38] LATCH SET/RESET (2 inputs)
[40] OR (2 to 16 inputs)
[42] AND (2 to 16 inputs)
[44] NOR (2 to 16 inputs)
[46] NAND (2 to 16 inputs)
[48] TIMER (1 to 32)
[50] ASSIGN VIRTUAL OUTPUT (1 to 96)
[52] SELF-TEST ERROR (see F141 for range)
[56] ACTIVE SETTING GROUP (1 to 6)
183 GGIO3.ST.UIntIn9.stVal
184 GGIO3.ST.UIntIn10.q
185 GGIO3.ST.UIntIn10.stVal
186 GGIO3.ST.UIntIn11.q
187 GGIO3.ST.UIntIn11.stVal
188 GGIO3.ST.UIntIn12.q
189 GGIO3.ST.UIntIn12.stVal
190 GGIO3.ST.UIntIn13.q
191 GGIO3.ST.UIntIn13.stVal
192 GGIO3.ST.UIntIn14.q
193 GGIO3.ST.UIntIn14.stVal
194 GGIO3.ST.UIntIn15.q
195 GGIO3.ST.UIntIn15.stVal
196 GGIO3.ST.UIntIn16.q
197 GGIO3.ST.UIntIn16.stVal
value month
0 January
1 February
2March
3April
4May
5June
6July
7 August
8 September
9 October
10 November
11 December
value day
0 Sunday
1 Monday
2 Tuesday
3 Wednesday
4 Thursday
5 Friday
6 Saturday
value instance
0First
1 Second
2Third
value GOOSE dataset item
3Fourth
4Last
Value Function
0 Disabled
1 Isolated
2 Forcible
value instance
