GE Multilin g60 - Page 629

GE Multilin G60 Generator Protection System B-83
APPENDIX B B.4 MEMORY MAPPING
B
F514
ENUMERATION: POWER SWING TRIP MODE
0 = Delayed, 1 = Early
F515
ENUMERATION ELEMENT INPUT MODE
0 = Signed, 1 = Absolute
F516
ENUMERATION ELEMENT COMPARE MODE
0 = Level, 1 = Delta
F517
ENUMERATION: ELEMENT DIRECTION OPERATION
0 = Over, 1 = Under
F518
ENUMERATION: FLEXELEMENT™ UNITS
0 = Milliseconds, 1 = Seconds, 2 = Minutes
F519
ENUMERATION: NON-VOLATILE LATCH
0 = Reset-Dominant, 1 = Set-Dominant
F522
ENUMERATION: TRANSDUCER DCMA OUTPUT RANGE
0 = –1 to 1 mA; 1 = 0 to 1 mA; 2 = 4 to 20 mA
F523
ENUMERATION: DNP OBJECTS 20, 22, AND 23 DEFAULT
VARIATION
F524
ENUMERATION: DNP OBJECT 21 DEFAULT VARIATION
F525
ENUMERATION: DNP OBJECT 32 DEFAULT VARIATION
F530
ENUMERATION: FRONT PANEL INTERFACE KEYPRESS
F531
ENUMERATION: LANGUAGE
0 = English, 1 = French, 2 = Chinese, 3 = Russian
F540
ENUMERATION: PMU POST-FILTER
0 = None, 1 = Symm-3-Point, 2 = Symm-5-Point,
3 = Symm-7-Point, 4 = Class M, 5 = Class P
F542
ENUMERATION: PMU TRIGGERING MODE
0 = Automatic Overwrite, 1 = Protected
bitmask default variation
01
12
25
36
bitmask Default Variation
01
12
29
310
bitmask default variation
01
12
23
34
45
57
value keypress value keypress value keypress
0 None 15 3 33 User PB 3
1 Menu 16 Enter 34 User PB 4
2 Message Up 17 Message
Down
35 User PB 5
37
~
18 0
~
36 User PB 6
4 8 19 Decimal 37 User PB 7
5 9 20 +/– 38 User PB 8
6 Help 21 Value Up 39 User PB 9
7 Message Left 22 Value Down 40 User PB 10
8 4 23 Reset 41 User PB 11
9 5 24 User 1 42 User PB 12
10 6 25 User 2 44 User 4
11 Escape 26 User 3 45 User 5
12 Message
Right
31 User PB 1 46 User 6
13 1 32 User PB 2 47 User 7
14 2
