GE P645

P64x Appendix C – Wiring Diagrams
P64x-TM-EN-1.2 C1
Model Cortec Option* External Connection Diagram Title Drawing-Sheet Issue
All
-
COMMS OPTIONS MICOM Px40 PLATFORM
10Px4001-1
J
P642
IO Option A
2 BIAS INPUT TRANSFORMER DIFFERENTIAL (8 I/P & 8 O/P) WITH 1 POLE VT INPUT (40TE)
10P64201-1
K
IO Option A
HIGH Z REF FOR 2 BIAS I/P TRANSFORMER DIFF SAME APPLIES TO WIRE HIGH Z REF FOR T2
10P64201-2
G
IO Option A 2 BIAS INPUT TRANSFORMER DIFFERENTIAL (8 I/P & 8 O/P) WITH 2 POLE VT INPUT (40TE) 10P64206-1 G
IO Option B 2 BIAS INPUT TRANSFORMER DIFFERENTIAL (8 I/P & 8 O/P + RTD) WITH 1 POLE VT INPUT (40TE) 10P64202-1 J
IO Option B 2 BIAS INPUT TRANSFORMER DIFFERENTIAL (8 I/P & 8 O/P + RTD) WITH 2 POLE VT INPUT (40TE) 10P64207-1 G
IO Option C 2 BIAS INPUT TRANSFORMER DIFFERENTIAL (8 I/P & 8 O/P + CLIO) WITH 1 POLE VT INPUT (40TE) 10P64203-1 J
IO Option C 2 BIAS INPUT TRANSFORMER DIFFERENTIAL (8 I/P & 8 O/P + CLIO) WITH 2 POLE VT INPUT (40TE) 10P64208-1 G
IO Option D 2 BIAS INPUT TRANSFORMER DIFFERENTIAL (12 I/P & 12 O/P) WITH 1 POLE VT INPUT (40TE) 10P64204-1 J
IO Option D 2 BIAS INPUT TRANSFORMER DIFFERENTIAL (12 I/P & 12 O/P) WITH 2 POLE VT INPUT (40TE) 10P64209-1 G
IO Option E 2 BIAS INPUT TRANSFORMER DIFFERENTIAL (8 I/P 12 O/P) WITH 1 POLE INPUT (40TE) 10P64205-1 J
IO Option E 2 BIAS INPUT TRANSFORMER DIFFERENTIAL (8 I/P 12 O/P) WITH 2 POLE INPUT (40TE) 10P64210-1 G
P643
IO Option A
3 BIAS INPUT TRANSFORMER DIFFERENTIAL (16 I/O & 16 O/P) WITH 4 POLE VT INPUTS (60TE)
10P64301-1, 10P64301-2
F, I
IO Option A
HIGH Z REF FOR 3 BIAS I/P TRANSFORMER DIFF SAME APPLIES TO WIRE HIGH Z REF FOR T2 &T3
10P64301-3
D
IO Option B
3 BIAS INPUT TRANSFORMER DIFFERENTIAL (16 I/O & 16 O/P + RTD) WITH 4 POLE VT INPUTS (60TE)
10P64302-1, 10P64302-2
F, I
IO Option C
3 BIAS INPUT TRANSFORMER DIFFERENTIAL (16 I/O & 16 O/P + CLIO) WITH 4 POLE VT INPUTS (60TE)
10P64303-1, 10P64303-2
G, I
IO Option D
3 BIAS INPUT TRANSFORMER DIFFERENTIAL (24 I/O & 16 O/P) WITH 4 POLE VT INPUTS (60TE)
10P64304-1, 10P64304-2
G, I
IO Option E
3 BIAS INPUT TRANSFORMER DIFFERENTIAL (16 I/O & 24 O/P) WITH 4 POLE VT INPUTS (60TE)
10P64305-1, 10P64305-2
F, I
IO Option F
3 BIAS INPUT TRANSFORMER DIFFERENTIAL (16 I/P 20 O/P) WITH 4 POLE VT INPUT (60TE)
10P64306-1, 10P64306-2
F, I
IO Option G
3 BIAS INPUT TRANSFORMER DIFFERENTIAL (40 I/O & 24 O/P) WITH 4 POLE VT INPUTS (80TE)
10P64307-1, 10P64307-2
C, D
IO Option H
3 BIAS INPUT TRANSFORMER DIFFERENTIAL (40 I/O & 16 O/P+RTD) WITH 4 POLE VT INPUTS (80TE)
10P64308-1, 10P64308-2
D, D
IO Option J
3 BIAS INPUT TRANSFORMER DIFFERENTIAL (40 I/O & 16 O/P+CLIO) WITH 4 POLE VT INPUTS (80TE)
10P64309-1, 10P64309-2
C, D
IO Option K
3 BIAS INPUT TRANSFORMER DIFFERENTIAL (40 I/O & 8 O/P+RTD+CLIO) WITH 4 POLE VT I/P (80TE)
10P64310-1, 10P64310-2
C, D
IO Option L
3 BIAS INPUT TRANSFORMER DIFFERENTIAL (40 I/O & 20 O/P) WITH 4 POLE VT INPUTS (80TE)
10P64311-1, 10P64311-2
C, D
IO Option M
3 BIAS INPUT TRANSFORMER DIFFERENTIAL (40 I/O & 12 O/P+RTD) WITH 4 POLE VT INPUTS (80TE)
10P64312-1, 10P64312-2
C, D
IO Option N
3 BIAS INPUT TRANSFORMER DIFFERENTIAL (40 I/O & 12 O/P+CLIO) WITH 4 POLE VT INPUTS (80TE)
10P64313-1, 10P64313-2
C, D
P645
IO Option A
5 BIAS INPUT TRANSFORMER DIFFERENTIAL (16 I/P & 16 O/P) WITH 4 POLE VT INPUTS (60TE)
10P64501-1, 10P64501-2
E, J
IO Option A
HIGH Z REF FOR 5 BIAS I/P TRANSFORMER DIFF. SAME APPLIES TO WIRE HIGH Z REF FOR T2,T3,T4,T5
10P64501-3
G
IO Option B
5 BIAS INPUT TRANSFORMER DIFFERENTIAL (16 I/P & 16 O/P + RTD) WITH 4 POLE VT INPUTS (60TE)
10P64502-1, 10P64502-2
E, I
IO Option C
5 BIAS INPUT TRANSFORMER DIFFERENTIAL (16 I/P & 16 O/P + CLIO) WITH 4 POLE VT INPUTS (60TE)
10P64503-1, 10P64503-2
E, I
IO Option D
5 BIAS INPUT TRANSFORMER DIFFERENTIAL (24 I/P & 16 O/P) WITH 4 POLE VT INPUTS (60TE)
10P64504-1, 10P64504-2
E, I
IO Option E
5 BIAS INPUT TRANSFORMER DIFFERENTIAL (16 I/P & 24 O/P) WITH 4 POLE VT INPUTS (60TE)
10P64505-1, 10P64505-2
E, I
IO Option J
5 BIAS INPUT TRANSFORMER DIFF. (24 I/P & 24 O/P + CLIO & RTD) WITH 4 POLE VT INPUTS (80TE)
10P64506-1, 10P64506-2
F, I
IO Option K
5 BIAS INPUT TRANSFORMER DIFFERENTIAL (24 I/P 20 O/P) WITH 4 POLE VT INPUTS (60TE)
10P64507-1, 10P64507-2
E, H
IO Option P
5 BIAS INPUT TRANSFORMER DIFF. (24 I/P 20 O/P + CLIO & RTD)) WITH 4 POLE VT INPUTS (80TE)
10P64508-1, 10P64508-2
E, H
IO Option T
5 BIAS INPUT TRANSFORMER DIFF. (16 I/P 24 O/P + CLIO & RTD) WITH 4 POLE VT INPUTS (80TE)
10P64509-1, 10P64509-2
E, H
IO Option U
5 BIAS INPUT TRANSFORMER DIFFERENTIAL (40 I/P & 24 O/P) WITH 4 POLE VT INPUTS (80TE)
10P64514-1, 10P64514-2
C, D
IO Option V
5 BIAS INPUT TRANSFORMER DIFFERENTIAL (40 I/P & 16 O/P+RTD) WITH 4 POLE VT INPUTS (80TE)
10P64515-1, 10P64515-2
C, D
IO Option W
5 BIAS INPUT TRANSFORMER DIFFERENTIAL (40 I/P & 16 O/P+CLIO) WITH 4 POLE VT INPUTS (80TE)
10P64516-1, 10P64516-2
D, D
IO Option X
5 BIAS INPUT TRANSFORMER DIFFERENTIAL (40 I/P & 8 O/P+CLIO+RTD) WITH 4 POLE VT INPUTS (80TE)
10P64517-1, 10P64517-2
C, D
IO Option Y
5 BIAS INPUT TRANSFORMER DIFFERENTIAL (40 I/P & 20 O/P) WITH 4 POLE VT INPUTS (80TE)
10P64518-1, 10P64518-2
C, D
IO Option Z
5 BIAS INPUT TRANSFORMER DIFFERENTIAL (40 I/P & 12 O/P+RTD) WITH 4 POLE VT INPUTS (80TE)
10P64519-1, 10P64519-2
C, C
IO Option 1
5 BIAS INPUT TRANSFORMER DIFFERENTIAL (40 I/P & 12 O/P+CLIO) WITH 4 POLE VT INPUTS (80TE)
10P64520-1, 10P64520-2
C, D
* When selecting the applicable wiring diagram(s), refer to appropriate model’s Cortec.
