– 26 –
(Continued next page)
Burner Assembly (PGS975 Shown)
Burner Cap
Oven Vent
Maintop Burner Assembly
(PGS975 Shown with Grates Removed)
Igniter (Electrode)
Burner Orifi ce
Burner Orifi ce
Burner Base
Burner Head Assembly
T-20 Torx Screws
