GE PGS908 Technical Service Guide

– 44 –
Convection Fan Assemblies
The convection fan assembly consists of the fan cover, fan blade, and motor. It is located on the back wall of
the oven.
Refer to the schematic in the back of this manual for circuitry for your specifi c model.
Note:
Models PGS968 and PGS975 utilize a 2-speed fan motor.•
Model PGS908 does not have a convection fan.•
Fan Blade
Oven Liner
Oven Insultion
Outer Back Panel
Convection Fan
Screws
(4)
Support
Oven Cavity
Mounting Screws (3)
Convection Fan
Mounting Screws (3)
Fan Blade Nut
PGS975 CONVECTION FAN ASSEMBLY
Fan Cycle Information
Fan
will
only
start
to
operate
10
seconds after
the
burners
turn
off
.
The fan will only run in one direction with the following parameters:
High Speed Low Speed Pause/Off
Convection Bake 3 7 50 Repeat
Convection Roast Continuousl
y
00
Convection Fan Operation - All times are in seconds
