GE PGS908 Technical Service Guide

– 71 –
Models PGS975
Burner Output Rating - Natural Gas 5 in. W.C.P.
Burner BTU Rate Orifi ce Size
RF 18,000 No. 49
RR 5,000 No. 56
LF 11,000 No. 52
LR 9,100 No. 54
Bake 15,000
Broil 12,000
Burner Output Rating - L.P. Gas 10 in. W.C.P.
Burner BTU Rate Orifi ce Size
RF 15,000 No. 59
RR 5,000 No. 69
LF 11,000 No. 63
LR 9,100 No. 65
Bake 15,000
Broil 12,000
Relay Contacts Operation Test and Control
Voltage Check
Terminals Voltage
L1- to N 120 VAC all the time
BAKE to N 120 VAC when in BAKE mode
BROIL to N 120 VAC when in BROIL mode
Switch Contacts
Door Motor
to N
120 VAC locking or unlocking
NOTE
Temperature/Mode Selection Necessary for •
operation of Relay contacts.
Voltage must be present across terminals L1 to •
N for control to operate. Transformer primary is
150 to 200Ω measured “L1” to “N” with power
removed.
