– 28 –
Rear View
(PGS975 Shown with Back Cover and Cooktop Lockout Cover Removed)
Convection Fan Motor
Broil Igniter Wires
Bake Igniter Wires
Cooling Fan
Cooling Fan
Control Valve
Cooktop
Lockout
Valve
