GE MEDICAL SYSTEMS PRECISION RXI® AND PRECISION RXI® VERSION E SYSTEM DRAWINGS
DIRECTION 5142538 -100, REVISION 6
Page 8
Cables between POSITIONER CABINET (Pos. cab.) and POSITIONER (Pos. ) BASE SYSTEM
rf GMM # GE Part # cables description mt ft source destination mm Inch C \ mm C \ inch
P06 56298 5129626 Tilting Potentiometer 7 23 Pos. - Tilting Potentiometer - 3PT1 Pos. cab. - I/O interface board - 25S3CP1 7 0.28 12 x 5 x 14 .47 x .2 x .55
P07 56299 5129627 Tilting Tachymetric dynamo 7 23 Pos. - Tilting Tachymetric dynamo - 3DT1
Pos. cab. - Bus maxi drivers board -
23S9MVS1- pin 3,4,5
5 0.2 Crimped terminal
P08 56300 5129628 Tilting Motor 7 23 Pos. - Tilting Motor - 3MT1
Pos. cab. - Bus maxi drivers board -
23S9MVS1- pin 1,2
10 0.39 Crimped terminal
P09 56301 5129629 Positioner ground 7 23
Pos. - Tilting/Elevation group ground -
3GND1/2
Pos. cab. - Ground - 20GND0 7 0.28 Crimped terminal
P10 56302 5129630
Tilting and Elevation Table
Safety
7 23
Pos. - Tilting and Elevation Table Safety -
3Fc1, 3Fc2
Pos. cab. - I/O interface board - 25S3AMP1 5 0.2 12 x 5 x 14 .47 x .2 x .55
P11 56303 5129631
Elevation Table
Potentiometer
7 23 Pos. - Elevation Table Potentiometer - 3PT2 Pos. cab. - I/O interface board - 25S3CP2 7 0.28 12 x 5 x 14 .47 x .2 x .55
P12 56304 5129633
Elevation Table Tachymetric
dynamo
7 23
Pos. - Elevation Table Tachymetric Dynamo -
3TB2 [3DT2]
Pos. cab. - Bus maxi drivers board -
23S9MVS2-pin3,4,5
5 0.2 Crimped terminal
P13 56305 5129634 Elevation Table Motor 7 23 Pos. - Elevation Table Motor - 3TB2 [3MT2]
Pos. cab. - Bus maxi drivers board -
23S9MVS2-pin 1,2
10 0.39 Crimped terminal
P14 56306 5129635 Stand X-Ray Potentiometer 7 23
Pos. - Stand X-Ray Potentiometer - 3CP3
[3PT3]
Pos. cab. - I/O interface board - 25S3CP3 7 0.28 12 x 5 x 14 .47 x .2 x .55
P15 56307 5129636
Stand X-Ray Tachymetric
dynamo
7 23
Pos. - Stand X-Ray Tachymetric dynamo -
3TB3 [3DT3]
Pos. cab. - Bus maxi drivers board -
23S9MVS3-pin 3,4,5
5 0.28 Crimped terminal
P16 56308 5129637 Stand X-Ray Motor 7 23 Pos. - Stand X-Ray Motor - 3TB3 [3MT3]
Pos. cab. - Bus maxi drivers board -
23S9MVS3-pin 1,2
10 0.39 Crimped terminal
P17 56309 5129638 Focal Film Distance signals 7 23 Pos. - Focal Film Distance Microswitch - 3Fc5
Pos. cab. - Bus step drivers board -
24S9AMP2
5 0.2 12 x 5 x 14 .47 x .2 x .55
P18 56310 5129639 Focal Film Distance Motor 7 23
Pos. - Focal Film Distance Motor - 3TB5
[3MT5]
Pos. cab. - Bus step drivers board -
24S9MVS8
9 0.35 30 x15 x18 1.18 x .59 x .7
7 23
Pos. - Collimator Motors - 3CM1 [3MT7, 3MT8,
3MT9]
Pos. cab. - Bus mini drivers board -
23S10MVS3
13 0.51 70 x15 x18 2.75 x .59 x.7
P19 56311 5129640 Collimator
7 23
Pos. - Collimator potentiometers - 3CM1
[3PT7, 3PT8, 3PT9]
Pos. cab. - I/O interface board - 25S3CP7,
25S3CP8, 25S3CP9
9 0.35 12 x 5 x 14 .47 x .2 x .55
P20 56312 5129792
Display on Compressor
group
7 23 Pos. - X-Ray Housing Tube group - 3TB6 Pos. cab. - I/O interface board - 25S3AMP9 9 0.35 23 x 7 x 14 .91 x .28 x .55
P21 56313 5129793 Compressor Motor 7 23
Pos. - Compressor group Motor - 3TB6 [
3MT6]
Pos. cab. - Bus mini drivers board -
23S10MVS2-1/2
7 0.28 Crimped terminal
P22 56314 5129794 Tabletop Transversal signals 7 23
Pos. - Tabletop Transversal Microswithes -
3Fc11, 3Fc12
Pos. cab. - I/O interface board - 25S3AMP6 5 0.2 12 x 5 x 14 .47 x .2 x .55
P23 56315 5129795 Tabletop Transversal Motor 7 23
Pos. - Tabletop Transversal Motor - 3TB10 [
3MT10]
Pos. cab. - Bus mini drivers board -
23S10MVS2-3/4
7 0.28 Crimped terminal
P24 56316 5129796 SFD Potentiometer 7 23 Pos. - SFD Potentiometer - 3PT4 Pos. cab. - I/O interface board - 25S3CP4 7 0.28 12 x 5 x 14 .47 x .2 x .55
P25 56317 5129797 SFD Tachymetric dynamo 7 23 Pos. - SFD Tachymetric Dynamo - 3DT4
Pos. cab. - Bus maxi drivers board -
23S9MVS4-pin 3,4,5
5 0.2 Crimped terminal
P26 56318 5129798 SFD Motor 7 23 Pos. - SFD Motor - 3MT4
Pos. cab. - Bus maxi drivers board -
23S9MVS4-pin 1,2
10 0.39 Crimped terminal
P27 56319 5129799 Remote Keyboard 7 23 Pos. - Remote Keyboard - 3S1AMP1 Pos. cab. - I/O interface board - 25S3AMP8 9 0.35 23 x 7 x 14 .91 x .28 x .55
