GE MEDICAL SYSTEMS PRECISION RXI® AND PRECISION RXI® VERSION E SYSTEM DRAWINGS
DIRECTION 5142538 -100, REVISION 6
Page 9
P28 56320 5129800
Emergency Stop and I.I.
safety
7 23
Pos. - SFD Group - Emerg.Stop and I.I. safety
3PULS1/3TB4
Pos. cab. - I/O interface board - 25S3AMP3 5 0.2 12 x 5 x 14 .47 x .2 x .55
P29 56321 5129801 Parallel Diaphragms Motor 7 23
Pos. - Parallel Diaphragms Motor - 3TB13
[3MT13]
Pos. cab. - Bus step drivers board -
24S9MVS2
9 0.35 30 x15 x18 1.18 x.59 x .7
P30 56322 5129802 Crossed Diaphragms Motor 7 23
Pos. - Crossed Diaphragms Motor - 3TB14
[3MT14]
Pos. cab. - Bus step drivers board -
24S9MVS3
9 0.35 30 x15 x18 1.18 x.59 x .7
P31 56323 5129803 Grid Motor 7 23 Pos. - Grid Motor - 3TB15 [3MT15]
Pos. cab. - Bus step drivers board -
24S9MVS4
9 0.35 30 x15 x18 1.18 x.59 x .7
P32 56324 5129804 Longitudinal Cassette Motor 7 23
Pos. - Longitudinal Cassette Motor - 3TB11
[3MT11]
Pos. cab. - Bus step drivers board -
24S9MVS6
9 0.35 30 x15 x18 1.18 x.59 x .7
P33 56325 5129805 Transversal Cassette Motor 7 23
Pos. - Transversal Cassette Motor - 3TB12
[3MT12]
Pos. cab. - Bus step drivers board -
24S9MVS9
9 0.35 30 x15 x18 1.18 x.59 x .7
P34 56326 5129806 I.I. Elevation Motor 7 23 Pos. - I.I. Elevation Motor - 3TB16 [3MT16]
Pos. cab. - Bus step drivers board -
24S9MVS7
9 0.35 30 x15 x18 1.18 x.59 x .7
P35 56327 5129807 SFD Reference Photocell 7 23
Pos. - SFD Reference Photocell board -
3S3AMP9
Pos. cab. - Bus step drivers board -
24S9AMP1
9 0.35 23 x 7 x 14 .9 x .28 x .55
P36 56328 5129808
Potentiometers for Film
dimensions
7 23
Pos. - Cassette group - 3CP10/
3CP11[3PT10/3PT11]
Pos. cab. - I/O interface board - 25S3CP10,
25S3CP11
8 0.32 12 x 5 x 14 .47 x .2 x .55
P37 56329 5129809
Longitudinal Tabletop
Potentiometer
7 23
Pos. - Longitudinal Tabletop Potentiometer -
3CP17
Pos. cab. - I/O interface board - 25S3CP6 7 0.28 12 x 5 x 14 .47 x .2 x .55
P38 56330 5129810
Longitudinal Tabletop Tach.
dynamo
7 23
Pos. - Longitudinal Tabletop dynamo - 3TB17
[3DT17]
Pos. cab. - Bus maxi drivers board -
23S9MVS17-pin3,4,5
5 0.2 Crimped terminal
P39 56331 5129811 Longitudinal Tabletop Motor 7 23
Pos. - Longitudinal Tabletop Motor - 3TB17 /
3MT2
Pos. cab. - Bus maxi drivers board -
23S9MVS17-pin 1,2
10 0.39 Crimped terminal
P40 56332 5131393 Rotating Footrest Motor 7 23
Pos. - Rotating Footrest Motor - 3CM18
[3MT18]
Pos. cab. - Bus mini drivers board -
23S10MVS2-5/6
7 0.28 Crimped terminal
P41 56363A 5262738
Room double Foot switch
extender
7 23
Pos. - Room double Foot switch connector -
3CM20
Pos. cab. - I/O interface board - 25S3AMP5 5 0.2 23 x 5 x 14 .91 x .2 x .55
I02 56297 5129813
Microphone and loudspeaker
secondary
7 23
Pos. - Over the Pos - Microphone and
loudspeaker secondary (507/1SA)
Pos. cab. - Intercom power supply/amplifier
(528)
7 0.28 Crimped terminal
Inside POSITIONER CABINET (Pos.Cab.) cables for BASE SYSTEM
rf GMM # GE Part # cables description mt ft source destination mm inch C \ mm C \ inch
I04 55513 5142355 Intercom power supply / / Pos.Cab. - Power Transformer - 22TR1
Pos.Cab. - Intercom power supply/amplifier
(528)
5 0.2 internal
Inside POSITIONER (Pos. ) cables for BASE SYSTEM
rf GMM # GE Part # cables description mt ft source destination mm inch C \ mm C \ inch
P42 55269 N/A
Tilting and Elevation Table
safety
/ / Pos. - Tilting Table safety - 3Fc1 Pos. - Elevation Table safety - 3Fc2 6 0.24 internal
P43 55944 N/A
Stand X-Ray Potentiometer
extender
/ / Pos. - Stand X-Ray Group - 3PT3 Pos. - Stand X-Ray Group - 3CP3 7 0.28 internal
P44 55245 N/A Stand X-Ray Group Ground / / Pos. - Stand X-Ray Group Ground - 3GND3
Pos. - Tilting/Elevation Group Ground -
3GND1/2
7 0.28 internal
P45 55314 N/A
Variable Focal Film Distance
Ground
/ / Pos. - Focal Film Distance Ground - 3GND5 Pos. - Stand X-Ray Group Ground - 3GND3 7 0.28 internal
P46 55530 N/A
Collimator Ground with Fixed
FFD (opz.)
/ / Pos. - Collimator Ground - 3GND7 Pos. - Stand X-Ray Group Ground - 3GND3 6 0.24 internal
To Next Page
