GE MEDICAL SYSTEMS PRECISION RXI® AND PRECISION RXI® VERSION E SYSTEM DRAWINGS
DIRECTION 5142538 -100, REVISION 6
Page 12
Inside POSITIONER CABINET (Pos. cab.) cables for DIGITAL SYSTEM
rf GMM # GE Part # cables description mt ft source destination mm inch C \ mm C \ inch
D02 068-113 5130678 Power supply I.T./GIM / /
Pos. cab. - Infimed Isolator Transformer
(120Vac Out)
Pos. cab. - GIM (120Vac In) 9 0.35 internal
Cable between POSITIONER CABINET (Pos. cab.) and GENERATOR CABINET (Gen. cab.) for BASE SYSTEM
rf GMM # GE Part # cables description mt ft source destination mm inch C \ mm C \ inch
T03 56380 5130679
Generator/Positioner
Interface signals
4 13,1 Gen. cab. -TDI board - J6
Pos. cab. - I/O Interface board - 25S3,
AMP11, AMP12 , AMP13
11 0.43 70x16 x 60 2.7 x .63 x 2.4
Cables between POSITIONER CABINET (Pos. cab.) and GENERATOR CABINET (Gen. Cab.) for ANALOG SYSTEM
rf GMM # GE Part # cables description mt ft source destination mm inch C \ mm C \ inch
N01 56176A 5130681
Power supply Nical panel
and ABS
4 13,1
Gen. Cab. - Room interface board – TB7/TB8
(24Vdc Out) and TDI board – J7 pin1, 2 e 3
Pos. cab. - Nical Interface board – SC1 10 0.4 30x15x18 1.18 x .59 x .7
N02 55967 5130682
Power supply 220 Vac input
for Monitor
4 13,1
Gen. Cab. - Room interface board TB7/TB10
(230Vac Out)
Pos. cab. - Nical panel – MV1 (230Vac In) 6 0.24 Crimped terminal
N20 56401 5142352
Generator/N33 Interface
signals
4 13,1 Gen. Cab. - TDI board – J4C (only for N 33)
Pos. cab. - Nical Interface board - J4C (only
for N33)
5 0.2 12x12 x 25 .47 x .47 x .98
N21 56402 5142353
Generator/N33 Interface
signals
4 13,1 Gen. Cab. - TDI board – J4D (only for N 33)
Pos. cab. - Nical Interface board - J4D (only
for N 33)
5 0.2 12x12 x 25 .47 x .47 x .98
N22 56403 5142354
Generator/N33 Interface
signals
4 13,1 Gen. Cab. - TDI board – J2 (only for N 33)
Pos. cab. - Nical Interface board - J2 (only
for N 33)
5 0.2 10x10 x 15 .39 x .39 x .59
Cables between POSITIONER CABINET (Pos. cab.) and GENERATOR CABINET (Gen. cab.) for DIGITAL SYSTEM
rf
GMM #
GE Part # cables description mt ft source destination mm inch C \ mm C \ inch
D03
726-619-
G1
5130683
Generator/Digital Interface
signals
4 13,1 Gen. cab. - TDI board - J4A Pos. cab. - GIM - P1 port1 5 0.2 12x12 x 25 .47 x .47 x .98
D04
726-619-
G2
5130684
Generator/DigitaI Interface
signals
4 13,1 Gen. cab. - TDI board - J4B Pos. cab. - GIM - P1 port2 5 0.2 12x12 x 25 .47 x .47 x .98
D05
726-619-
G3
5130685
Generator/Digital Interface
signals
4 13,1 Gen. cab. - TDI board - J4C Pos. cab. - GIM - P1 port3 5 0.2 12x12 x 25 .47 x .47 x .98
D06
726-619-
G4
5130686
Generator/Digital Interface
signals
4 13,1 Gen. cab. - TDI board - J4D Pos. cab. - GIM - P1 port4 5 0.2 12x12 x 25 .47 x .47 x .98
D43
726-619-
G6
5178104
Generator/Digital Interface
signals
4 13,1 Gen. cab. - TDI board - J4F Pos. cab. - GIM - P1 port6 5 0.2 12x12 x 25 .47 x .47 x .98
D07
726-618-
G1
5130687
Generator/Digital Interface
signals
4 13,1 Gen. cab. - TDI board - J3 Pos. cab. - GIM - P2 port1 5 0.2 10x10 x 15 .39 x .39 x .59
D08
726-618-
G2
5130688
Generator/Digital Interface
signals
4 13,1 Gen. cab. - TDI board - J2 Pos. cab. - GIM - P2 port2 5 0.2 10x10 x 15 .39 x .39 x .59
D09
726-618-
G3
5130689
Generator/Digital Interface
signals
4 13,1 Gen. cab. - TDI board - J1 Pos. cab. - GIM - P3 port1 5 0.2 10x10 x 15 .39 x .39 x .59
D10
726-654-
G1
5130690 ABS - PFL Interface signals 4 13,1 Gen. cab. - TDI board - J7 Pos. cab. - GIM - P18 abs, P20 drive output 5 0.2 Crimped terminal
