GE MEDICAL SYSTEMS PRECISION RXI® AND PRECISION RXI® VERSION E SYSTEM DRAWINGS
DIRECTION 5142538 -100, REVISION 6
Page 11
Cables between POSITIONER CABINET (Pos. cab.) and DIAGNOSTIC ROOM for BASE SYSTEM
rf GMM # GE Part # cables description mt ft source destination mm Inch C \ mm C \ inch
P67 55317 5130656
Safety for low ceiling
extender
15 49,2
Diagnostic Room - Photocell above the Pos. -
3CM2 [3Fc3]
Pos. cab. - I/O interface board - 25S3AMP2 7 0.28 12 x 5 x 14 .47 x .2 x .55
P68 55279 5130657 Safety for low ceiling 2 6,6
Diagnostic Room - Photocell above the Pos. -
3Fc3
Diagnostic Room - Photocell above the Pos.
- 3CM2 [3Fc3]
7 0.28 18x18 x 65 .7 x .7 x 2.6
55628
1
5172381 Room double Foot switch 3 9,8
Diagnostic Room - Over the Pos. - double Foot
switch
Pos. - Room double Foot switch connector -
3CM20
8 0.32 18x18 x 65 .7 x .7 x 2.6
P69
56662
2
5269029 Room double Foot switch 3 9,8
Diagnostic Room - Over the Pos. - double Foot
switch
Pos. - Room double Foot switch connector -
3CM20
8 0.32 18x18 x 65 .7 x .7 x 2.6
Cables between GENERATOR CABINET (Gen. Cab.) and MAIN SUPPLY PANEL for BASE SYSTEM
rf GMM # GE Part # cables description mt ft source destination mm inch C \ mm C \ inch
G01 * 56359 5130663
Power Supply Generator
(3phases)
10 32,8 Main power supply panel MS1 (400/480Vac) Gen. Cab. - Power Input board - [ L1-L2-L3] 25 0.98 Crimped terminal
G02 * 56360 5130665 Ground Generator 10 32,8 Main power supply panel NE1 (GND) Gen. Cab. - Power Input board – GND 10 0.4 Crimped terminal
Cables between POSITIONER CABINET (Pos. cab.) and MAIN SUPPLY PANEL for BASE SYSTEM
rf GMM # GE Part # cables description mt ft source destination mm inch C \ mm C \ inch
T01 * 55430 5130667
Power Supply positioner
(1phases)
10 32,8 Main power supply panel MS2 (230/277Vac)
Pos. cab. - 22Filter (230Vac) or 22TR3
(277Vac)
10 0.39 Crimped terminal
T02 * 55429 5130669 Ground positioner 10 32,8 Main power ground panel NE2 (GND) Pos. cab. - 20GND0 7 0.28 Crimped terminal
Cable between POSITIONER CABINET (Pos. cab.) and MAIN SUPPLY PANEL for DIGITAL SYSTEM
rf GMM # GE Part # cables description mt ft source destination mm inch C \ mm C \ inch
D01 * 56119 5130672 Power supply I.T. (1phases) 10 32,8 Main power cabinet MS3 (120/230Vac)
Pos. cab. - Infimed Isolator Transf. (120Vac
or 230Vac)
8 0.32 Crimped terminal
Inside POSITIONER CABINET (Pos. cab.) cables for ANALOG SYSTEM
rf GMM # GE Part # cables description mt ft source destination mm inch C \ mm C \ inch
N03 55969 5130674
Nical/Positioner Interface
signals
/ / Pos. cab. - I/O interface board - 25S3 AMP10 Pos. cab. - Nical interface board - AMP1 7 0.28 internal
N04 56113 5130677
Nical N33/Positioner
Interface signals
/ /
Pos. cab. - I/O interface board - 25S3 AMP10A
(only for N33)
Pos. cab. - Nical interface board - AMP3
(only for N33)
5 0.2 internal
N23 56406 5142357
Nical N33/Positioner video
out signals
/ / Pos. cab. - Nical N33 Panel - V3 (only for N33)
Pos. cab. - Nical interface board - V3 (only
for N33)
7 0.28 internal
1
GMM#:55628 - (P69 - Room double Foot switch), it uses a single release for Prep and Rad
2
GMM#56662 - (p69 - Room double Foot switch), it uses a double release for Prep and Rad
