GE VAT2000 User Manual

6. Control Functions and Parameter Settings
6-71
The signal conversion circuit is according the following combination.
Setting
No.
A-IN
forward/
reverse
B-IN
forward/
reverse
Z-IN
forward/
reverse
AB
inter-
change
0---
1 Reverse - -
2-Reverse-
3 Reverse Reverse -
4 - - Reverse
5 Reverse - Reverse
6 - Reverse Reverse
7 Reverse Reverse Reverse
No inter-
change
8---
9 Reverse - -
10 - Reverse -
11 Reverse Reverse -
12 - - Reverse
13 Reverse - Reverse
14 - Reverse Reverse
15 Reverse Reverse Reverse
AB inter-
change
C51-0
Encoder UVW pulse type selection for Permanent Magnet motor (PM)
A position encoder which outputs a 3ph 180º square wave is used for permanent magnet
motors. Check PCST3301 manual of optional U2KV23DN3 PM encoder card.
