GE VAT2000 User Manual

Appendix
A-2


400V Series
Item Specifications
System 400V Series (XxxKx)
Type (VAT2000-U2KX_) 00K4 00K7 01P5 02P2 04K0 05K5 07K5 11K0 15K0 18K5 22K0 30K0 37K0 45K0
Rated capacity
[kVA]
(Note 1)
1.0 1.7 2.5 3.8 5.9 9.0 11.7 15.9 21.4 25.6 30.4 41.5 50.0 60.0
Max. continuous
rated current
[A]
(Note 2)
1.52.53.65.58.6131723313744607287
Max. applicable
motor
[kW]
(Note 3)
0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45
Working ambient
temperature
−
10 to 50°C
Carrier frequency
(Note 5)
Standard 10kHz, variable between 1 and 15kHz
Standard 4kHz
variable
between 1 and
15kHz
Constant torque
(Note 8)
Overload current
rating
150% for 1min.
Rated capacity
[kVA]
(Note 1)
1.7 2.5 3.8 5.9 9.0 11.7 15.9 21.4 25.6 30.4 41.5 50.5 55.0 75.0
Max. continuous
rated current
[A]
(Note 2)
2.5 3.6 5.5 8.6 13 17 23 31 37 44 60 73 84 108
Max. applicable
motor
[kW]
(Note 3)
0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55
Working ambient
temperature
−
10 to 50°C
Carrier frequency
(Note 5)
Standard 4kHz, variable between 1 and 15kHz
Inverter ratin
g
Variable torque
Overload current
rating
120% for 1min.
Power
supply
Rated input AC
voltage: rated
input frequency
(Note 6)
380~460V
±
10%, 50/60Hz
±
5%
480V
−
10%, +5% 50/60Hz
±
5%
Rated output
voltage
380~480V (Max.)
(Note 7)
Output
(Note
9)
Output frequency 0.1~440Hz
Structure Wall-mounted
Enclosure IP20 IP00
Approx. weight
(kg)
3.5 6 13 26 50 50
Cooling method Self-cooling Forced air cooling
Const-
ruction
Paint color Munsell N4.0
Working environment Indoors, Relative humidity: 95%RH or below (no dew condensation), Altitude: 1000m or less,
Vibration: 3.0m/s
2
or less
Freedom from corrosive or explosive gases, steam, dust, oil mist or cotton lint.
