Appendix
A-4
Note 6) This inverter is subject to the EC Low Voltage Directives. The rated input voltage will be 380 to
415V to comply to the EC Low Voltage Directives.
Note 7) An output voltage exceeding the input voltage cannot be attained.
Note 8) When using the speed sensor-less vector control, the vector control with speed sensor, or the
PM motor control, select the applicable motor from the max. continuous rated current [A] of
the constant torque.
Note 9) The rated output voltage for the vector control without speed sensor, the vector control with
speed sensor, or the PM motor control is as follows.
200V series : 160V/180V/185V respectively in respect to the input voltage 200V/220V, 230V.
400V series : 300V/320V/360V/370V respectively in respect to the input voltage
380V/400V/440V/460V. The output frequency range will be 0 to 120Hz
(7200min
−
1
).
