3. Test Operation and Adjustment
3-16
(8) Move the digit with the
key, and using the knob, raise the frequency to 50Hz. Then, press
the
key. The new value is stored and output frequency will rise to 50Hz.
CAUTION
A 10-second acceleration and 20-second deceleration ramp time are set as defaults. The motor will slowly
increase its speed to the set value. Increase the speed by approx. 10Hz steps at a time with the
knob.
(9) Press the key when the motor speed reaches 50Hz. The display will decrease to 0.00 in 20
seconds. The "FWD" or "REV" LED will blink for two seconds while the DC-brake is applied and the
motor will stop.
(10) Press the
key to test the reverse run.
This completes the test operation with the operation panel.
Refer to Chapter 4 and make the adjustments according to the user application.
