4. Operation Panel (Keypad)
4-4
(Continued from previous page)
Block-B Parameter Mode
: Parameters changed infrequently during the normal usage
Basic function settings
Output rating (B00-0~7)
Motor circuit constant (IM) (B02-0~1)
Frequency skip (B05-0~5)
Ratio interlock setting (B06-0~3)
Extended function settings
Acceleration/deceleration time (B10-0~5)
Program frequency setting (B11-0~8)
V/f Middle Point (B17-0~3)
Over current limit (B18-0~6)
Automatic tuning function (B19-0)
Output rating (dual drive) (B20-0~5)
Frequency setting (dual drive) (B21-0~1)
Acceleration/deceleration time (dual drive) (B22-0~3)
Torque boost (dual drive) (B23-0~1)
DC brake (dual drive) (B24-0~1)
Overcurrent limit (dual drive) (B25-0~1)
Software option function settings
Software option application (B40-0~1)
Program ramp - acceleration (B41-0~7)
Program ramp – deceleration (B42-0~7)
PID Control (B43-0~4)
Multi-pump control (B44-0~3)
Traverse run (B45-0~6)
Pattern Run (B50-0~B59-3)
(Continued on next page)
Fig. 4-2 (2) Parameter configuration
