6. Control Functions and Parameter Settings
6-2
Monitor parameters list
ApplicationNo. Parameter Unit Remarks
ST V/f VEC PM
D05 – Minor fault monitor
0 Minor fault The internal minor fault status will display.
The correspondence of each LED segment and signal is
shown in the next page.
D06 – Pattern run monitor
0 Step number Displays the current operation step number.
1 Remaining time Hrs Displays the remaining time of current step.
D07 – Pump operation status monitor
0 Pump operation status Displays the ON/OFF status of the pumps
The correspondence of each LED segment and signal is
shown below.
1 Next ON pump No. “0” is displayed when all pumps are ON
2 Next OFF pump No. “0” is displayed when all pumps are OFF
3 Passage time Hrs Displays the continuous ON /OFF time of the current pump.
It is cleared when the pump operation is changeover
PSO1 (Pump 1)
PSO2 (Pump 2)
PSO3 (Pump 3)
PSO4 (Pump 4)
PSO5 (Pump 5)
Pump operation status monitor (D07-0)
