System Configuration
Venue 50 – Basic Service Manual 3-53
5447566-100 English Rev. 7
Power Module Rating Plate/Warning Lable
1. Rating Plate/Warning Label Explanations
2. If the lock button moves to the unlock position while the
Venue 50 is in use, the Power Module needs to be
re-mounted.
For the explanation of other labels/Icons on Rating Plate/Label,
please refer to the latest revision of Venue 50 Basic User
Manual.
NOTE: Please refer to the operation manual of each peripheral for
information needed by the user to operate the system safely.
Table 3-16: Label/Icon Explanations
Label/Icon Explanations
The power is supplied by the
Alternating Current (AC)
The power is supplied by the battery
when the Alternating Current (AC) is
off.
To Next Page
