Disassembly/Re-assembly
Venue 50 – Basic Service Manual 8-7
5447566-100 English Rev. 7
Tools needed for servicing Venue 50
NOTE: This is ultra-portable device in small size, please carefully keep
all the screws, cables aside during service activities.
NOTE: When disassembling the Top Assy, please make sure to lay it
on soft and stable surface to avoid scratching the LCD.
Table 8-1: Standard tools list for Venue 50
No Part Name Part No. QTY Screw Description
Screwdriver
Description
1 Screw 5138465 30 Screw FH M2.5X5 (NL) Phillips #1
2 Screw 5162727 5 Screw M3x25 (NL) TORX #10
3 Screw 5308509 2 Screw M3x15 (NL) TORX #10
4 Screw 2327793 14 D2 Screw SJ2836-87 M3x8 Phillips #1
5 Screw 5307880 5 Screw M3x825 with Cushion Phillips #1
6 Screw 2327764 7 D2 Screw M2X3 (NYLOK) Phillips #2
7 Screw 5307881 7 Screw M2x3 OD 7.80 Phillips #1
8 Screw 5307883 8 Screw M2.5x4 OD 3.60 Phillips #1
9 Screw 5307887 6 Screw FH M2.5x15 (NL) Phillips #1
To Next Page
