Scanning
Vscan Extend – User Manual 5-13
5721203-100 Rev. D
Probe and Presets (continued)
NOTE: Vscan Extend with Dual probe (shallow and deep) can be used
for procedural guidance.
Table 5-4: Linear transducer in Dual Probe (shallow scanning) presets
Linear transducer
in Dual Probe
(shallow scanning)
Preset Optimized for
Vascular • Veins
• Arteries
Soft tissue • Small organs
• Pediatric (recommended minimum weight:
4kg)
• Musculoskeletal - including Long bone, Hip,
Knee, Shoulder and Elbow
Lung • Thoracic/Pleural motion
• Fluid detection
Adult Cephalic Various cephalic structures
Ophthalmic* Ophthalmic
* Ophthalmic is available as an option for certain countries but is NOT available in the USA, China and
Japan.
