DescriptionPart
Process variable (PV) axis and measurement unit1
Graph area2
Controlled variable (CV) axis and measurement unit3
Legend4
Xcellerex XDM 50-1000, XDUO 100-1000 mixers Operating Instructions 29251615 AD 115
4 User interface
4.5 Trend screens
