Appendix C
Download audit and data logs
Introduction
This appendix provides information on about how to download audit and data logs from
the local control panel to an external computer.
The logs are stored as .csv files on the SD card on the local control panel. The logs can
be exported to an external computer using Ethernet or USB.
Parameter abbreviations
The following parameter abbreviations are used in the local control software .csv data
log file.
UnitDefinitionTerm/Abbreviation
0% to 100%Pump 1 speedSC201_Acid_PID_Out-
put
0% to 100%Pump 2 speedSC202_Base_PID_Out-
put
Not applicablepHAIT121_PH1_PV
Not applicablepH
1
AIT122_1_PH2_PV
millisiemens per centimeter
(mS/cm)
Conductivity
2
AIT122_2_Conductiv-
ity_PV
As applicableProcess variablePV
revolutions per minute (rpm)Agitator speedSC244_Agitator_PV
°CTemperature (sensor 1)TE161_Tempera-
ture1_PV
°CTemperature (sensor 2)TE162_Tempera-
ture2_PV
kgMixer vessel weightWT176_Mixer-
Weight_PV
1
Used if XDUO mixer has dual pH monitoring (PH1 and PH2).
304 Xcellerex XDM 50-1000, XDUO 100-1000 mixers Operating Instructions 29251615 AD
C Download audit and data logs
