10.2 SP, CV and PV units and ranges
Ranges for SP, CV, and PV
The following SP, CV, and PV units and ranges are set in the local control software for the XDUO mixers.
Process variable
(PV)
Controlled variable
(CV)
Setpoint
(SP)
Controller loop
0 to 200 rpmNot applicable10 to 200 revolutions
per minute (rpm)
Agitator speed
0 to 150 mS/cmNot applicableNot applicableConductivity
0 to 140% to 100%0 to 14pH
Not applicable0% to 100%Not applicablePumps
0°C to 100°C0% to 75%0°C to 60°CVessel temperature
The following table shows the upper limit for vessel weight PV for all XDUO mixer sizes.
Maximal PV (kg)Mixer vessel size
125100 L
250200 L
625500 L
12501000 L
Xcellerex XDM 50-1000, XDUO 100-1000 mixers Operating Instructions 29251615 AD 279
10 Reference information
10.2 SP, CV and PV units and ranges
