10.7.1 TCU requirements
TCU requirements - 50 L, 100 L,
200 L mixer
ValueParameterProperty
5 kWCooling capacityGeneral requirements
5 kWHeating capacity
2.8 bar (40 psi g)Fluid outlet pressureProcess requirements
40 L/minFluid outlet flow
-10°CFluid outlet minimum temperature
65°CFluid outlet maximum temperature
1.5″Connector size
4 to 20 mASetpointRemote control interface
(for XDUO mixers only)
RequiredOn/Off emergency stop
TCU requirements - 500 L, 1000 L
mixer
ValueParameterProperty
9 kWCooling capacity, 500 L mixerGeneral requirements
15 kWCooling capacity, 1000 L mixer
9 kWHeating capacity, 500 L and 1000 L mixer
2.8 bar (40 psi g)Fluid outlet pressureProcess requirements
60 L/minFluid outlet flow
-10°CFluid outlet minimum temperature
65°CFluid outlet maximum temperature
1.5″Connector size
Xcellerex XDM 50-1000, XDUO 100-1000 mixers Operating Instructions 29251615 AD 285
