4.3.2 Alarm configuration screens
Description
Alarm configuration screens are available for the following functionalities:
•
Agitator (Agitator Alarm Config)
•
Conductivity (Conductivity Alarm Config)
•
pH (pH Alarm Config)
•
Temperature (Temperature Alarm Config)
•
Weight (Weight Alarm Config)
All five alarm configuration screens have similar layout. The following alarms can be set
for each function:
•
High High Alarm
•
High Alarm
•
Low Alarm
•
Low Low Alarm
The alarm levels are set by the user according to process specific requirements. Only
Supervisor and Administrator can set the alarm limits.
The user opens the alarm configuration screens by tapping ALARM CONFIG on Agitator
Detail, Conductivity Detail, pH Detail, Temperature Detail or Weight Detail screens.
See Section 7.3.7 Set alarm limits, on page 227 for instructions how to set the alarm limits.
Xcellerex XDM 50-1000, XDUO 100-1000 mixers Operating Instructions 29251615 AD 95
4 User interface
4.3 Alarm screens
4.3.2 Alarm configuration screens
