3.2.2 Illustration of Xcellerex XDM mixer
Introduction
The following illustrations show a full configuration of a jacketed 200 L XDM mixer. The
configuration of each mixer may vary according to the selected optional features.
Front view
4
3
2
1
10
9
8
76
5
FunctionPart
Weight monitor display1
Temperature monitor display2
pH/conductivity transmitter display3
