Tubing in the pump
The following illustration shows the direction of the liquid flow through the pump, when
the pump is running in a clockwise direction.
See the following section for tubing installation instructions.
184 Xcellerex XDM 50-1000, XDUO 100-1000 mixers Operating Instructions 29251615 AD
6 Preparation
6.6 Prepare the pumps
